2006
项目 零配件号码 Qty。 最近的部分号码 描述
1 OE48501/1 1 OE48501/1 进气岐管
7 OE50904 6 OE50904 密合垫 - IND 的岐管
8 UF1557 4 UF1557 固定螺钉
9 0920054 4 0920054 垫圈
10 ST15903 4 ST15903 垫圈
11 UF1563 2 UF1563 固定螺钉
12 0920054 2 0920054 垫圈
13 ST15903 2 ST15903 垫圈
14 UF1572 6 UF1572 固定螺钉
15 0920054 6 0920054 垫圈
16 ST15903 6 ST15903 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE48501/1 1 OE48501/1 INDUCTION MANIFOLD
7 OE50904 6 OE50904 GASKET - IND MANIFOLD
8 UF1557 4 UF1557 SETSCREW
9 0920054 4 0920054 WASHER
10 ST15903 4 ST15903 WASHER
11 UF1563 2 UF1563 SETSCREW
12 0920054 2 0920054 WASHER
13 ST15903 2 ST15903 WASHER
14 UF1572 6 UF1572 SETSCREW
15 0920054 6 0920054 WASHER
16 ST15903 6 ST15903 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 ST11611 5 ST11611 INSERT
3 ST20137 3 ST20137 PLUG
4 ST49209 3 ST49209 WASHER
5 ST11621 4 ST11621I INSERT
6 ST11602 2 ST11602 INSERT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE48879 1 OE48879 DUCT
2 OE50891 1 OE50891 GASKET
3 UF1504 5 UF1504 BOLT
4 0920053 5 0920053 WASHER
5 ST15902 5 ST15902 WASHER


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE48432 1 OE48432 连杆
2 UF1560 1 UF1560 固定螺钉
3 UF4355 1 UF4355 螺帽
4 0920054 1 0920054 垫圈
5 ST15903 2 ST15903 垫圈
6 UF1522 1 UF1522 螺拴
7 0920053 1 0920053 垫圈
8 UF1618 1 UF1618 固定螺钉
10 0920055 1 0920055 垫圈
11 ST15904 1 ST15904 垫圈
13 OE48429 1 OE51410/1 Z 托架
15 UF1519 1 UF1519 螺拴
16 0920053 1 0920053 垫圈
17 ST15902 1 ST15902 垫圈
18 UF1519 2 UF1519 螺拴
19 0920053 2 0920053 垫圈
20 ST15902 2 ST15902 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE48432 1 OE48432 LINK
2 UF1560 1 UF1560 SETSCREW
3 UF4355 1 UF4355 NUT
4 0920054 1 0920054 WASHER
5 ST15903 2 ST15903 WASHER
6 UF1522 1 UF1522 BOLT
7 0920053 1 0920053 WASHER
8 UF1618 1 UF1618 SETSCREW
10 0920055 1 0920055 WASHER
11 ST15904 1 ST15904 WASHER
13 OE48429 1 OE51410/1Z BRACKET
15 UF1519 1 UF1519 BOLT
16 0920053 1 0920053 WASHER
17 ST15902 1 ST15902 WASHER
18 UF1519 2 UF1519 BOLT
19 0920053 2 0920053 WASHER
20 ST15902 2 ST15902 WASHER



项目 零配件号码 Qty。 最近的部分号码 描述
1 OE48208Z 1 OE48208Z 拉紧带轮
8 OE51875 1 OE51875 紧张
9 OE42737 1 OE42737 填隙用木片
10 OE44596 1 OE44596 垫圈
11 UF1604 1 UF1604 固定螺钉
12 0920055 1 0920055 垫圈
13 UF1606 2 UF1606 固定螺钉
14 0920055 2 0920055 垫圈
15 ST15904 2 ST15904 垫圈
16 UF1650 1 UF1650 固定螺钉
17 ST16262 1 ST16262 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OE48207 1 OE48207 TENSIONER PULLEY
3 OE44687 2 OE44687 BALL BEARING
4 OE47653 1 OE47653 SPACER
5 OE47652 1 OE47652 SHAFT
6 2722A022 1 2722A022 CIRCLIP
7 ST48985 2 ST48985 CIRCLIP


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE51850/1 1 OE51850/1 凸轮轴
2 OE51851 1 OE51851 凸轮轴传动机构
4 OE49049 5 OE49049 螺拴
4 ST29281 4 ST29281 螺旋
7 OE6870 1 OE6870 板
8 OE4421 1 OE4421 销
10 OE51849 1 OE51849 推力板
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE51850/1 1 OE51850/1 CAMSHAFT
2 OE51851 1 OE51851 CAMSHAFT GEAR
4 OE49049 5 OE49049 BOLT
4 ST29281 4 ST29281 SCREW
7 OE6870 1 OE6870 PLATE
8 OE4421 1 OE4421 PIN
10 OE51849 1 OE51849 THRUST PLATE
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OE51692 1 Check History CAMSHAFT GEAR
5 KC515 1 KC515I WOODRUFF KEY
5 KC516 1 KC516 WOODRUFF KEY
5 KC517 1 KC517 WOODRUFF KEY
5 KC518 1 KC518 WOODRUFF KEY
6 ST33605 2 ST33605 PLUG


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50473 1 OE50473 压缩机
(1) OE50473R 1 OE50473R 压缩机 -交换
2 OE51176 1 OE51176 密合垫 -压缩机
3 ST43565 3 ST43565 螺拴 U94619Y
3 ST43566 3 ST43566 公制的螺拴 U94618Y
4 2318 A209 3 2318 A209 螺帽
5 2134 A010 3 2134 A010 垫圈
6 KRP1296 1 KRP1296 压缩机服务装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50473 1 OE50473 COMPRESSOR
(1) OE50473R 1 OE50473R COMPRESSOR - EXCHANGE
2 OE51176 1 OE51176 GASKET - COMPRESSOR
3 ST43565 3 ST43565 BOLT U94619Y
3 ST43566 3 ST43566 METRIC BOLT U94618Y
4 2318A209 3 2318A209 NUT
5 2134A010 3 2134A010 WASHER
6 KRP1296 1 KRP1296 COMPRESSOR SERVICE KIT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE36176/13 1 OE36176/13 PIPE
2 OE50787 1 OE50787 CLIP
3 ST20554 1 ST20554I ADAPTOR
4 ST49891 1 ST49891 WASHER
5 OE49183 1 OE49183 ADAPTOR
6 ST49892 1 ST49892 WASHER
7 OE49714 1 OE49714 ADAPTOR
8 ST49892 1 ST49892 WASHER
9 ST46401 2 ST46401 CLIP
10 OE50107 1 OE50107 PIPE
11 OE49960 1 OE49960 ADAPTOR
12 ST49896 1 ST49896 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50192 1 OE50192 OIL PIPE
5 ST20552 1 CV72340 ADAPTOR
6 ST49852 1 ST49852 WASHER
7 OE7661 2 OE7661 CLIP
8 OE7660 2 OE7660 BUSH
9 OE49124 1 OE49124 BANJO BOLT
10 ST49940 2 ST49940 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OD2412 1 OD2412 BANJO FITTING
3 ST16654 1 ST16654 UNION NUT
4 ST16679 1 ST16679 NIPPLE



项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49800/一 1 OE49800/一 连杆组合 对 7 LB 14 OZ 的 7 LB 10 OZ
1 OE49800/B 1 OE49800/B 连杆组合 对 8 LB 2 OZ 的 7 LB 14 OZ
1 OE49800/C 1 OE49800/C 连杆组合 对 8 LB 6 OZ 的 8 LB 2 OZ
1 OE49800/D 1 OE49800/D 连杆组合 对 8 LB 10 OZ 的 8 LB 6 OZ
1 OE49800/E 1 OE49800/E 连杆组合 对 8 LB 14 OZ 的 8 LB 10 OZ
1 OE49800/Y 1 OE49800/Y 连杆组合 对 7 LB 6 OZ 的 7 LB 2 OZ
1 OE49800/Z 1 OE49800/Z 连杆组合 对 7 LB 10 OZ 的 7 LB 6 OZ
1 OE49800 6 OE49800 连杆组合
7 KRP3002/010 1 KRP3002/010 大头 BRG 装备 -U/S
7 KRP3002/020 1 KRP3002/020 大头 BRG 装备 -U/S
7 KRP3002/030 1 KRP3002/030 大头 BRG 装备 -U/S
7 KRP3002/040 1 KRP3002/040 大头 BRG 装备 -U/S
7 KRP3002 1 KRP3002 大头桥承装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49800/A 1 OE49800/A CON ROD ASSEMBLY 7LB 10OZ TO  7LB 14OZ
1 OE49800/B 1 OE49800/B CON ROD ASSEMBLY 7LB 14OZ TO  8LB 2OZ
1 OE49800/C 1 OE49800/C CON ROD ASSEMBLY 8LB 2OZ TO  8LB 6OZ
1 OE49800/D 1 OE49800/D CON ROD ASSEMBLY 8LB 6OZ TO  8LB 10OZ
1 OE49800/E 1 OE49800/E CON ROD ASSEMBLY 8LB 10OZ TO  8LB 14OZ
1 OE49800/Y 1 OE49800/Y CON ROD ASSEMBLY 7LB 2OZ TO  7LB 6OZ
1 OE49800/Z 1 OE49800/Z CON ROD ASSEMBLY 7LB 6OZ TO  7LB 10OZ
1 OE49800 6 OE49800 CON ROD ASSEMBLY
7 KRP3002/010 1 KRP3002/010 BIG END BRG KIT - U/S
7 KRP3002/020 1 KRP3002/020 BIG END BRG KIT - U/S
7 KRP3002/030 1 KRP3002/030 BIG END BRG KIT - U/S
7 KRP3002/040 1 KRP3002/040 BIG END BRG KIT - U/S
7 KRP3002 1 KRP3002 BIG END BEARING KIT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 ROD
3 1 CAP
4 OE50510 2 OE50510 SMALL END BUSH
5 OE23311 2 OE23311 CON ROD BOLT
6 OE3735 2 OE3735 CON ROD NUT



项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49800/一 1 OE49800/一 连杆组合 对 7 LB 14 OZ 的 7 LB 10 OZ
1 OE49800/B 1 OE49800/B 连杆组合 对 8 LB 2 OZ 的 7 LB 14 OZ
1 OE49800/C 1 OE49800/C 连杆组合 对 8 LB 6 OZ 的 8 LB 2 OZ
1 OE49800/D 1 OE49800/D 连杆组合 对 8 LB 10 OZ 的 8 LB 6 OZ
1 OE49800/E 1 OE49800/E 连杆组合 对 8 LB 14 OZ 的 8 LB 10 OZ
1 OE49800/Y 1 OE49800/Y 连杆组合 对 7 LB 6 OZ 的 7 LB 2 OZ
1 OE49800/Z 1 OE49800/Z 连杆组合 对 7 LB 10 OZ 的 7 LB 6 OZ
1 OE49800 6 OE49800 连杆组合
7 KRP3008/010 1 KRP3008/010 大头 BRG 装备 -U/S
7 KRP3008/020 1 KRP3008/020 大头 BRG 装备 -U/S
7 KRP3008/030 1 KRP3008/030 大头 BRG 装备 -U/S
7 KRP3008/040 1 KRP3008/040 大头 BRG 装备 -U/S
7 KRP3008 1 KRP3008 大头桥承装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49800/A 1 OE49800/A CON ROD ASSEMBLY 7LB 10OZ TO  7LB 14OZ
1 OE49800/B 1 OE49800/B CON ROD ASSEMBLY 7LB 14OZ TO  8LB 2OZ
1 OE49800/C 1 OE49800/C CON ROD ASSEMBLY 8LB 2OZ TO  8LB 6OZ
1 OE49800/D 1 OE49800/D CON ROD ASSEMBLY 8LB 6OZ TO  8LB 10OZ
1 OE49800/E 1 OE49800/E CON ROD ASSEMBLY 8LB 10OZ TO  8LB 14OZ
1 OE49800/Y 1 OE49800/Y CON ROD ASSEMBLY 7LB 2OZ TO  7LB 6OZ
1 OE49800/Z 1 OE49800/Z CON ROD ASSEMBLY 7LB 6OZ TO  7LB 10OZ
1 OE49800 6 OE49800 CON ROD ASSEMBLY
7 KRP3008/010 1 KRP3008/010 BIG END BRG KIT - U/S
7 KRP3008/020 1 KRP3008/020 BIG END BRG KIT - U/S
7 KRP3008/030 1 KRP3008/030 BIG END BRG KIT - U/S
7 KRP3008/040 1 KRP3008/040 BIG END BRG KIT - U/S
7 KRP3008 1 KRP3008 BIG END BEARING KIT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 ROD
3 1 CAP
4 OE50510 2 OE50510 SMALL END BUSH
5 OE23311 2 OE23311 CON ROD BOLT
6 OE3735 2 OE3735 CON ROD NUT


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49907 1 OE49907 水泵
(1) OE49907R 1 OE49907R 水泵 -交换
15 OE51169 1 OE51169 密合垫 - 水的泵
16 UF1515 1 UF1515 螺拴
16 UF1522 1 UF1522 螺拴
17 UF4354 1 UF4354 螺帽
18 0920053 1 0920053 垫圈
19 UF1512 1 UF1512 螺拴
20 0920053 1 0920053 垫圈
21 UF1516 2 UF1516 螺拴
22 0920053 2 0920053 垫圈
23 UF1518 1 UF1518 螺拴
23 UF1524 1 UF1524I 螺拴
24 UF4354 3 UF4354 螺帽
25 0920053 1 0920053 垫圈
26 UF1510 2 UF1510 螺拴
26 UF1522 2 UF1522 螺拴
27 0920053 2 0920053 垫圈
28 UF1504 1 UF1504 螺拴
29 0920053 1 0920053 垫圈
30 UF1510 3 UF1510 螺拴
31 0920053 3 0920053 垫圈
32 UF1514 1 UF1514 螺拴
32 UF1524 1 UF1524I 螺拴
33 0920053 1 0920053 垫圈
34 KRP1201 1 KRP1201 密封装备
35 KRP1202 1 KRP1202 修理装备 - 水的泵
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49907 1 OE49907 WATER PUMP
(1) OE49907R 1 OE49907R WATER PUMP - EXCHANGE
15 OE51169 1 OE51169 GASKET - WATER PUMP
16 UF1515 1 UF1515 BOLT
16 UF1522 1 UF1522 BOLT
17 UF4354 1 UF4354 NUT
18 0920053 1 0920053 WASHER
19 UF1512 1 UF1512 BOLT
20 0920053 1 0920053 WASHER
21 UF1516 2 UF1516 BOLT
22 0920053 2 0920053 WASHER
23 UF1518 1 UF1518 BOLT
23 UF1524 1 UF1524I BOLT
24 UF4354 3 UF4354 NUT
25 0920053 1 0920053 WASHER
26 UF1510 2 UF1510 BOLT
26 UF1522 2 UF1522 BOLT
27 0920053 2 0920053 WASHER
28 UF1504 1 UF1504 BOLT
29 0920053 1 0920053 WASHER
30 UF1510 3 UF1510 BOLT
31 0920053 3 0920053 WASHER
32 UF1514 1 UF1514 BOLT
32 UF1524 1 UF1524I BOLT
33 0920053 1 0920053 WASHER
34 KRP1201 1 KRP1201 SEAL KIT
35 KRP1202 1 KRP1202 REPAIR KIT - WATER PUMP
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 1 HOUSING
4 CV13387 1 CV13387 SEAL - WATER PUMP
5 CV13386 1 CV13386 SEAL - WATER PUMP
6 OE41708 1 OE41708 IMPELLER
7 OE49171 1 OE49171 BEARING
8 OE47659 1 OE47659 SHAFT
9 OE41704 1 OE41704 DISTANCE PIECE
10 OE4717 1 OE4717 DISTANCE PIECE
11 OE1427 1 OE1427 BALL BEARING
12 2721351 1 2721351 CIRCLIP
13 OE41705 1 OE41705 SEAL
14 OE49388 1 OE49388 HUB
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 CV13386 1 CV13386 SEAL - WATER PUMP
3 OE51169 1 OE51169 GASKET - WATER PUMP
4 ST45119 2 ST45119 SEAL - O RING
5 CV13387 1 CV13387 SEAL - WATER PUMP
6 OE52596 1 OE52596 GASKET - WATER PUMP
7 OE52156 1 OE52156 GASKET - WATER PUMP
8 OE41705 1 OE41705 SEAL
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 CV13386 1 CV13386 SEAL - WATER PUMP
3 OE51169 1 OE51169 GASKET - WATER PUMP
4 ST45119 2 ST45119 SEAL - O RING
5 CV13387 1 CV13387 SEAL - WATER PUMP
6 2721351 1 2721351 CIRCLIP
7 OE1427 1 OE1427 BALL BEARING
8 OE52596 1 OE52596 GASKET - WATER PUMP
9 OE52156 1 OE52156 GASKET - WATER PUMP
10 OE41704 1 OE41704 DISTANCE PIECE
11 OE41705 1 OE41705 SEAL
12 OE41708 1 OE41708 IMPELLER
13 OE4717 1 OE4717 DISTANCE PIECE
14 OE49171 1 OE49171 BEARING
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE2278 1 OE2278 CONNECTION
2 OE50888 1 OE50888 GASKET - THERMOSTAT HSG
3 ST20103 1 ST46078I PLUG
4 ST49853 1 ST49853 WASHER
5 UF1503 4 UF1503 BOLT
6 ST20606 4 ST20606 WASHER
27 4 WASHER
28 4 WASHER


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49337 1 OE49337 恒温器壳
2 OE48311 1 OE48311 密封 - O 的圈
3 OE47926 1 OE52769 恒温器
4 OE49338 1 OE49338 管
5 ST45119 6 ST45119 密封 - O 的圈
8 OE29192 1 OE29192 轧辊销
9 OE25649 1 OE25649 栓塞
10 ST49891 3 ST49891 垫圈
13 UF1570 2 UF1570 固定螺钉
14 0920054 2 0920054 垫圈
15 ST20133 3 ST20133I 栓塞
16 ST49856 1 ST49856 垫圈
17 UF1565 1 UF1565 固定螺钉
18 0920054 1 0920054 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49337 1 OE49337 THERMOSTAT HOUSING
2 OE48311 1 OE48311 SEAL - O RING
3 OE47926 1 OE52769 THERMOSTAT
4 OE49338 1 OE49338 PIPE
5 ST45119 6 ST45119 SEAL - O RING
8 OE29192 1 OE29192 ROLL PIN
9 OE25649 1 OE25649 PLUG
10 ST49891 3 ST49891 WASHER
13 UF1570 2 UF1570 SETSCREW
14 0920054 2 0920054 WASHER
15 ST20133 3 ST20133I PLUG
16 ST49856 1 ST49856 WASHER
17 UF1565 1 UF1565 SETSCREW
18 0920054 1 0920054 WASHER


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50716 1 OE50716 气缸台组合
11 KRP3101/010 1 KRP3101/010 要点桥承装备 -U/S
11 KRP3101 1 KRP3101 要点桥承装备
12 KRP3200/013 1 KRP3200/013 插入垫圈装备 -O/S
12 KRP3200 1 KRP3200 推力垫圈装备
13 OE50629 1 OE50629 凸轮轴衬套
14 UF5403 6 UF5403 栓塞
15 ST49891 6 ST49891 垫圈
16 ST46076 1 ST46076I 栓塞
17 ST49851 1 ST49851 垫圈
18 OE2970 4 OE2970 螺旋
19 ST45105 12 ST45105 密封 - O 的圈
20 OE1595 6 OE1595 线桥
21 OE2814 4 OE2814 轧辊销
22 OE3385 1 OE52920I 栓塞
23 ST49887 1 ST49887 垫圈
24 OE48933 6 OE48933 喷射
25 ST10529 6 ST10529 密封 - O 的圈
27 UF1501 6 UF1501 螺拴
28 0920053 6 0920053 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50716 1 OE50716 CYLINDER BLOCK ASSEMBLY
11 KRP3101/010 1 KRP3101/010 MAIN BEARING KIT - U/S
11 KRP3101 1 KRP3101 MAIN BEARING KIT
12 KRP3200/013 1 KRP3200/013 THRUST WASHER KIT - O/S
12 KRP3200 1 KRP3200 THRUST WASHER KIT
13 OE50629 1 OE50629 CAMSHAFT BUSH
14 UF5403 6 UF5403 PLUG
15 ST49891 6 ST49891 WASHER
16 ST46076 1 ST46076I PLUG
17 ST49851 1 ST49851 WASHER
18 OE2970 4 OE2970 SCREW
19 ST45105 12 ST45105 SEAL - O RING
20 OE1595 6 OE1595 BOBBIN
21 OE2814 4 OE2814 ROLL PIN
22 OE3385 1 OE52920I PLUG
23 ST49887 1 ST49887 WASHER
24 OE48933 6 OE48933 JET
25 ST10529 6 ST10529 SEAL - O RING
27 UF1501 6 UF1501 BOLT
28 0920053 6 0920053 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 1 CYLINDER BLOCK KIT
3 OE48851 1 OE52182 HOUSING
4 OE50255 1 OE50255 SEAL - REAR END OIL
5 OE50895 1 OE50895 GASKET - OIL SEAL HOUSING
6 UF1502 8 UF1502 BOLT
7 0920053 8 0920053 WASHER
8 OE5111 2 OE5111 DOWEL
9 OE2296 2 OE2296 RING
10 OE281 1 OE281 COVER
11 OE50886 1 OE50886 GASKET
12 UF1504 4 UF1504 BOLT
13 0920053 4 0920053 WASHER
14 UF1502 1 UF1502 BOLT
15 ST49883 1 ST49883 WASHER
16 ST33628 1 ST33628 PLUG
17 OE25040 2 OE52315 STUD
18 OE39063 2 OE39063 NUT
19 OE46176 2 OE46176I WASHER
20 OE49593 1 OE49593 PLATE
21 OE50899 1 OE50899 GASKET - BLANKING PLATE
22 UF1503 2 UF1503 BOLT
23 0920053 2 0920053 WASHER
24 ST20137 2 ST20137 PLUG
25 ST49899 2 ST49858 WASHER
26 ST20133 1 ST20133I PLUG
27 ST49891 1 ST49891 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50716 1 OE50716 CYLINDER BLOCK ASSEMBLY
11 KRP3107/010 1 KRP3107/010 MAIN BEARING KIT - U/S
11 KRP3107/020 1 KRP3107/020 MAIN BEARING KIT - U/S
11 KRP3107/030 1 KRP3107/030 MAIN BEARING KIT - U/S
11 KRP3107/040 1 KRP3107/040 MAIN BEARING KIT - U/S
11 KRP3107 1 KRP3107 MAIN BEARING KIT
12 KRP3200/013 1 KRP3200/013 THRUST WASHER KIT - O/S
12 KRP3200 1 KRP3200 THRUST WASHER KIT
13 OE50629 1 OE50629 CAMSHAFT BUSH
14 UF5403 6 UF5403 PLUG
15 ST49891 6 ST49891 WASHER
16 ST46076 1 ST46076I PLUG
17 ST49851 1 ST49851 WASHER
18 OE2970 4 OE2970 SCREW
19 ST45105 12 ST45105 SEAL - O RING
20 OE1595 6 OE1595 BOBBIN
21 OE2814 4 OE2814 ROLL PIN
22 OE3385 1 OE52920I PLUG
23 ST49887 1 ST49887 WASHER
24 OE48933 6 OE48933 JET
25 ST10529 6 ST10529 SEAL - O RING
27 UF1501 6 UF1501 BOLT
28 0920053 6 0920053 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 7 CAP
3 OE2349 3 OE2349 DOWEL
4 OE51873 12 OE51873 SETSCREW
5 OE51874 8 OE51874 SETSCREW
6 UF1670 6 UF1670 SETSCREW
7 ST15905 6 ST15905 WASHER
8 UF5408 6 UF5408 PLUG
9 ST49896 6 ST49896 WASHER
10 ST43321 1 ST43321 PLUG
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 1 CYLINDER BLOCK KIT
3 OE48851 1 OE52182 HOUSING
4 OE50255 1 OE50255 SEAL - REAR END OIL
5 OE50895 1 OE50895 GASKET - OIL SEAL HOUSING
6 UF1502 8 UF1502 BOLT
7 0920053 8 0920053 WASHER
8 OE5111 2 OE5111 DOWEL
9 OE2296 2 OE2296 RING
10 OE281 1 OE281 COVER
11 OE50886 1 OE50886 GASKET
12 UF1504 4 UF1504 BOLT
13 0920053 4 0920053 WASHER
14 UF1502 1 UF1502 BOLT
15 ST49883 1 ST49883 WASHER
16 ST33628 1 ST33628 PLUG
17 OE25040 2 OE52315 STUD
18 OE39063 2 OE39063 NUT
19 OE46176 2 OE46176I WASHER
20 OE49593 1 OE49593 PLATE
21 OE50899 1 OE50899 GASKET - BLANKING PLATE
22 UF1503 2 UF1503 BOLT
23 0920053 2 0920053 WASHER
24 ST20137 2 ST20137 PLUG
25 ST49899 2 ST49858 WASHER
26 ST20133 1 ST20133I PLUG
27 ST49891 1 ST49891 WASHER
28 ST10650 1 ST10650 SEAL - O RING


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE48850/2 1 OE52803/3 曲柄桥装备
3 OE45631 1 OE45631 曲柄桥传动机构
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE48850/2 1 OE52803/3 CRANKSHAFT KIT
3 OE45631 1 OE45631 CRANKSHAFT GEAR
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 CRANKSHAFT
3 OE49149 1 OE45631 CRANKSHAFT GEAR
4 OE16842 1 OE16842 KEY
5 OE3844 6 OE3844 SNAP RING
6 OE42017 6 OE42017 PLUG
7 ST21914 6 ST21914 SEAL - O RING
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 OE42045 1 OE42045 NUT
4 UF1559 16 UF1559 SETSCREW
5 0920054 16 0920054 WASHER
7 OE8980 1 OE8980 SPACER
10 OE41858 1 OE41858 PLATE
12 OE47644 1 OE47644 CRANKSHAFT PULLEY


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50117 2 OE50117 汽缸盖装备 -主修科目
13 OE45920 6 OE45920 密封 - 阀转杆
14 OE50116 2 OE50116 密合垫 - 汽缸盖
15 OE50705 40 OE50705 螺拴
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50117 2 OE50117 CYLINDER HEAD KIT - MAJOR
13 OE45920 6 OE45920 SEAL - VALVE STEM
14 OE50116 2 OE50116 GASKET - CYLINDER HEAD
15 OE50705 40 OE50705 BOLT




项目 零配件号码 Qty。 最近的部分号码 描述
2 1 汽缸盖
3 OE50118 3 OE50118 嵌入内冷铁
3 OE50178 1 OE50178 嵌入内冷铁
4 OE49094 3 OE49094 嵌入内冷铁
4 OE50149 1 OE50149 嵌入内冷铁
5 OE43070 3 OE43070 阀导入
6 OE46001 3 OE46001 阀导入
7 OE50207 3 OE50207 套筒
8 OE49978 3 OE49978 封闭砂条
9 ST33602 1 ST33602 栓塞
10 ST33606 5 ST33606 栓塞
11 ST33609 5 ST33609 栓塞
12 ST33613 4 ST33613 栓塞
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 CYLINDER HEAD
3 OE50118 3 OE50118 INSERT
3 OE50178 1 OE50178 INSERT
4 OE49094 3 OE49094 INSERT
4 OE50149 1 OE50149 INSERT
5 OE43070 3 OE43070 VALVE GUIDE
6 OE46001 3 OE46001 VALVE GUIDE
7 OE50207 3 OE50207 SLEEVE
8 OE49978 3 OE49978 SEALING RING
9 ST33602 1 ST33602 PLUG
10 ST33606 5 ST33606 PLUG
11 ST33609 5 ST33609 PLUG
12 ST33613 4 ST33613 PLUG


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE47907 1 OE47907 炉衬 - 压八配合
1 OE51589 1 OE51589 炉衬 - 压八配合
1 OE52515 6 OE52921 炉衬 - 压八配合
2 OE52244 18 OE52244 密封
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE47907 1 OE47907 LINER - PRESS FIT
1 OE51589 1 OE51589 LINER - PRESS FIT
1 OE52515 6 OE52921 LINER - PRESS FIT
2 OE52244 18 OE52244 SEAL
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50208/10 1 OE50208/10 DIPSTICK
2 OE47411/7 1 OE47411/7 TUBE
3 OE9691 2 OE9691 CLIP
4 ST16626 1 ST16626 NUT
5 ST16606 1 ST16606 SLEEVE
6 ST19810 1 ST19810 ADAPTOR
7 ST49891 1 ST49891 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 UF1621 3 UF1621 BOLT
2 UF4356 3 UF4356 NUT
3 ST15904 3 ST15904 WASHER
4 0920055 3 0920055 WASHER
5 OE52632 7 OE52632 STUD
6 UF4356 7 UF4356 NUT
7 ST15904 7 ST15904 WASHER
8 0920055 7 0920055 WASHER


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50031 1 OE50031 排出岐管
2 OE49586 2 OE49586 排气肘管
3 OE50032 1 OE50032 排出岐管
4 OE52105 6 OE52105 密合垫 - 排出岐管
5 OE52323 16 OE52323 螺拴
7 UF1570 4 UF1570 固定螺钉
8 ST15903 4 ST15903 垫圈
9 OE42077 4 OE42077 图钉
10 OE7407 4 OE7407 螺帽
11 ST15903 4 ST15903 垫圈
12 OE42321 2 OE42321 栓塞
13 OE50033 2 OE50033 板
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50031 1 OE50031 EXHAUST MANIFOLD
2 OE49586 2 OE49586 EXHAUST ELBOW
3 OE50032 1 OE50032 EXHAUST MANIFOLD
4 OE52105 6 OE52105 GASKET - EXHAUST MANIFOLD
5 OE52323 16 OE52323 BOLT
7 UF1570 4 UF1570 SETSCREW
8 ST15903 4 ST15903 WASHER
9 OE42077 4 OE42077 STUD
10 OE7407 4 OE7407 NUT
11 ST15903 4 ST15903 WASHER
12 OE42321 2 OE42321 PLUG
13 OE50033 2 OE50033 PLATE
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
7 OE50398 1 OE50398 ADAPTOR
8 ST29260 6 ST29260 CAPSCREW


项目零配件号码 Qty. 最近的部分号码描述削减出自意见的削减
1 OG9557/1 1 OG9557/1 飞轮组合
5 OG8006 1 OG8006 板
6 UF1556 8 UF1556 固定螺钉
7 0920054 8 0920054 垫圈
8 OE50582 12 OE50582 螺拴
9 ST33398 1 ST33398 合钉
10 OG9599 1 OG9599 指针
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 FLYWHEEL
3 OG5739 1 OG5739 STARTER RING GEAR
4 ST28593 1 ST28593 DOWEL

项目 零配件号码 Qty。 最近的部分号码 描述
1 OG9616/1 Z 1 OG9616/1 Z 飞轮壳
5 UF1610 14 UF1610 固定螺钉
6 ST15904 14 ST15904 垫圈
7 OE51625 2 OE51625 合钉
8 OE539 2 OE539 圈
9 OE25649 1 OE25649 栓塞
10 ST49853 1 ST49853 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OG9616/1Z 1 OG9616/1Z FLYWHEEL HOUSING
5 UF1610 14 UF1610 SETSCREW
6 ST15904 14 ST15904 WASHER
7 OE51625 2 OE51625 DOWEL
8 OE539 2 OE539 RING
9 OE25649 1 OE25649 PLUG
10 ST49853 1 ST49853 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 UF1628 2 UF1628 BOLT
4 0920055 2 0920055 WASHER
11 ST10008 19 ST10008 INSERT
12 ST11611 4 ST11611 INSERT
13 ST11632 12 ST11632 INSERT
25 UF4556 2 UF4556 LOCKNUT


项目 零配件号码 Qty。 最近的部分号码 描述
1 OX7208/881 1 OX7208/881 燃料喷射泵
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 FUEL INJECTION PUMP
3 1 NAMEPLATE
4 OD4756 2 OD4756 SCREW
5 OD19994 1 OD19994 ADAPTOR
6 OD19995 1 OD19995 SEALING RING
7 OD19983 1 OD19983 UNION
8 ST49942 1 ST49942 WASHER
9 0920113 1 0920113 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50000 1 OE50000 BRACKET
2 OE49999 1 OE49999 BLOCK
3 UF1615 2 UF1615 BOLT
4 UF4356 2 UF4356 NUT
5 0920055 2 0920055 WASHER
6 ST29281 2 ST29281 SCREW
7 0920054 2 0920054 WASHER
8 ST29256 1 ST29256 CAPSCREW
9 0920054 1 0920054 WASHER
10 UF1577 2 UF1577 SETSCREW
11 UF4355 2 UF4355 NUT
12 0920055 2 0920055 WASHER
13 OE49631 1 OE49631 PLATE
14 OE49659 3 OE49659 STUD
15 OE50399 1 OE50399 STUD
16 ST10631 1 ST10631 SEAL - O RING
17 2318A209 4 2318A209 NUT
18 2134A010 4 2134A010 WASHER
20 ST10558 1 ST10558 SEAL - O RING

项目 零配件号码 Qty。 最近的部分号码 描述
1 OD20362 6 OD20362 注射器
(1) OD20362R 6 OD20362R 注射器 -交换
4 2411 B118 6 R2411B118 注射器垫圈
5 3662 K002 6 3662 K002 砂箱夹
6 OE51520 12 CV72464 螺拴
7 OE50256 6 OE50256 距离块
8 33813131 6 3311 A042 密封
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OD20364 1 OD20364 HOLDER
3 OD20250 1 OD20250 INJECTOR NOZZLE


项目 零配件号码 Qty。 最近的部分号码 描述
3 CV20523 5 CV20523 班卓琴螺拴
4 ST49938 10 ST49938 垫圈
5 CV20524 1 CV20524 班卓琴螺拴
6 ST49938 3 ST49938 垫圈
7 OD20149 1 OD20149 管
8 UF1606 3 UF1606 固定螺钉
9 0920055 3 0920055 垫圈
10 CV5365 1 CV5365 班卓琴螺拴
11 ST49851 2 ST49851 垫圈
12 OD20146 1 OD20146 班卓琴螺拴
13 ST49853 2 ST49853 垫圈
14 OD20301 1 OD20301 管
15 OD20292 1 OD20292 班卓琴螺拴
16 0920113 2 0920113 垫圈
17 OE5303 10 OE5303 夹
18 OD6039 10 OD6039 衬套
19 33141417 3 33141417 间隔器
20 OD20292 1 OD20292 班卓琴螺拴
21 0920113 2 0920113 垫圈
22 OD20299 1 OD20299 管
23 OD20300 1 OD20300 管
24 OD20292 1 OD20292 班卓琴螺拴
25 0920113 2 0920113 垫圈
26 UF1600 1 UF1600 固定螺钉
27 0920055 1 0920055 垫圈
28 CV19668 1 CV19668 管 - 漏走开
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 CV20523 5 CV20523 BANJO BOLT
4 ST49938 10 ST49938 WASHER
5 CV20524 1 CV20524 BANJO BOLT
6 ST49938 3 ST49938 WASHER
7 OD20149 1 OD20149 PIPE
8 UF1606 3 UF1606 SETSCREW
9 0920055 3 0920055 WASHER
10 CV5365 1 CV5365 BANJO BOLT
11 ST49851 2 ST49851 WASHER
12 OD20146 1 OD20146 BANJO BOLT
13 ST49853 2 ST49853 WASHER
14 OD20301 1 OD20301 PIPE
15 OD20292 1 OD20292 BANJO BOLT
16 0920113 2 0920113 WASHER
17 OE5303 10 OE5303 CLIP
18 OD6039 10 OD6039 BUSH
19 33141417 3 33141417 SPACER
20 OD20292 1 OD20292 BANJO BOLT
21 0920113 2 0920113 WASHER
22 OD20299 1 OD20299 PIPE
23 OD20300 1 OD20300 PIPE
24 OD20292 1 OD20292 BANJO BOLT
25 0920113 2 0920113 WASHER
26 UF1600 1 UF1600 SETSCREW
27 0920055 1 0920055 WASHER
28 CV19668 1 CV19668 PIPE - LEAK OFF


项目 零配件号码 Qty。 最近的部分号码 描述
1 OD20388 1 OD20388 以管输送 - 燃料 INJ 没有 1 CYL
2 OD20389 1 OD20389 以管输送 - 燃料 INJ 没有 2 CYL
3 OD20390 1 OD20390 以管输送 - 燃料 INJ 没有 3 CYL
4 OD20391 1 OD20391 以管输送 - 燃料 INJ 没有 4 CYL
5 OD20392 1 OD20392 以管输送 - 燃料 INJ 没有 5 CYL
6 OD20393 1 OD20393 以管输送 - 燃料 INJ 没有 6 CYL
7 0726505 4 0726505 固定螺钉
8 2211401 4 2211401 螺帽
9 36511123 8 36511123 板
10 36844134 8 36844134 挡板
11 0726505 1 0726505 固定螺钉
12 2211401 1 2211401 螺帽
13 36511123 2 36511123 板
14 36844116 2 36844116 管夹
15 UF1507 3 UF1507 螺拴
16 OD4784 3 OD4784 垫板
17 OD2426 3 OD2426 复缘
18 OD10407 6 OD10407 挡板
19 0920053 3 0920053 垫圈
20 UF1517 1 UF1517 螺拴
21 UF4354 1 UF4354 螺帽
22 OD2735 1 OD2735 复缘
23 OD10407 3 OD10407 挡板
24 OE6298 1 OE6298 板
25 OD2426 1 OD2426 复缘
26 OD4784 1 OD4784 垫板
27 0920053 1 0920053 垫圈
28 UF1509 1 UF1509 螺拴
29 0920053 1 0920053 垫圈
30 OD2735 4 OD2735 复缘
31 OD10407 4 OD10407 挡板
32 OE6298 4 OE6298 板
33 UF1516 1 UF1516 螺拴
34 OE49603 1 OE49603 嵌入内冷铁
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OD20388 1 OD20388 PIPE - FUEL INJ NO 1 CYL
2 OD20389 1 OD20389 PIPE - FUEL INJ NO 2 CYL
3 OD20390 1 OD20390 PIPE - FUEL INJ NO 3 CYL
4 OD20391 1 OD20391 PIPE - FUEL INJ NO 4 CYL
5 OD20392 1 OD20392 PIPE - FUEL INJ NO 5 CYL
6 OD20393 1 OD20393 PIPE - FUEL INJ NO 6 CYL
7 0726505 4 0726505 SETSCREW
8 2211401 4 2211401 NUT
9 36511123 8 36511123 PLATE
10 36844134 8 36844134 DAMPER
11 0726505 1 0726505 SETSCREW
12 2211401 1 2211401 NUT
13 36511123 2 36511123 PLATE
14 36844116 2 36844116 PIPE CLIP
15 UF1507 3 UF1507 BOLT
16 OD4784 3 OD4784 BASE PLATE
17 OD2426 3 OD2426 SHROUD
18 OD10407 6 OD10407 DAMPER
19 0920053 3 0920053 WASHER
20 UF1517 1 UF1517 BOLT
21 UF4354 1 UF4354 NUT
22 OD2735 1 OD2735 SHROUD
23 OD10407 3 OD10407 DAMPER
24 OE6298 1 OE6298 PLATE
25 OD2426 1 OD2426 SHROUD
26 OD4784 1 OD4784 BASE PLATE
27 0920053 1 0920053 WASHER
28 UF1509 1 UF1509 BOLT
29 0920053 1 0920053 WASHER
30 OD2735 4 OD2735 SHROUD
31 OD10407 4 OD10407 DAMPER
32 OE6298 4 OE6298 PLATE
33 UF1516 1 UF1516 BOLT
34 OE49603 1 OE49603 INSERT


项目 零配件号码 Qty。 最近的部分号码 描述
14 OD19596 1 OD19596 燃料过滤器
17 OE52248 1 OE52248 燃料过滤器冒口
25 UF1516 1 UF1516 螺拴
26 0920053 1 0920053 垫圈
27 ST15902 1 ST15902 垫圈
28 UF1517 1 UF1517 螺拴
29 0920053 1 0920053 垫圈
30 ST15902 1 ST15902 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
14 OD19596 1 OD19596 FUEL FILTER
17 OE52248 1 OE52248 FUEL FILTER HEAD
25 UF1516 1 UF1516 BOLT
26 0920053 1 0920053 WASHER
27 ST15902 1 ST15902 WASHER
28 UF1517 1 UF1517 BOLT
29 0920053 1 0920053 WASHER
30 ST15902 1 ST15902 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
18 ST11404 1 ST11404 INSERT
20 CV530 1 CV530 ADAPTOR
21 ST20527 2 ST20527 ADAPTOR
22 ST49852 2 ST49852 WASHER
31 ST46077 1 ST46077 PLUG
32 ST49852 1 ST49852 WASHER
33 ST46076 1 ST46076I PLUG
34 ST49851 1 ST49851 WASHER



项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50222 1 OE50222 车桥
2 OE51696 1 OE51696 惰轮传动机构
4 UF1604 1 UF1604 固定螺钉
5 0920055 1 0920055 垫圈
6 OE49015 1 OE49015 桥环
7 ST33264 1 ST33264I 合钉
8 OE5111 2 OE5111 合钉
9 UF1604 3 UF1604 固定螺钉
10 0920055 3 0920055 垫圈
11 OE2296 2 OE2296 圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50222 1 OE50222 AXLE
2 OE51696 1 OE51696 IDLER GEAR
4 UF1604 1 UF1604 SETSCREW
5 0920055 1 0920055 WASHER
6 OE49015 1 OE49015 COLLAR
7 ST33264 1 ST33264I DOWEL
8 OE5111 2 OE5111 DOWEL
9 UF1604 3 UF1604 SETSCREW
10 0920055 3 0920055 WASHER
11 OE2296 2 OE2296 RING


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49278/1 1 OE49278/1 套
6 OE51433 1 OE51433 TUBESTACK
7 OE44678 2 OE44678 密封 - O 的圈
10 ST24106 2 ST24106 螺旋
11 ST16256 2 ST16256 垫圈
12 ST26903 2 ST26903 垫圈
13 ST20136 4 ST20136 栓塞
14 ST49857 4 ST49857I 垫圈
15 UF1573 2 UF1573 固定螺钉
16 ST16260 2 0920054 垫圈
17 ST15903 2 ST15903 垫圈
18 UF1556 2 UF1556 固定螺钉
19 ST16260 2 0920054 垫圈
20 ST15903 2 ST15903 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49278/1 1 OE49278/1 CASING
6 OE51433 1 OE51433 TUBESTACK
7 OE44678 2 OE44678 SEAL - O RING
10 ST24106 2 ST24106 SCREW
11 ST16256 2 ST16256 WASHER
12 ST26903 2 ST26903 WASHER
13 ST20136 4 ST20136 PLUG
14 ST49857 4 ST49857I WASHER
15 UF1573 2 UF1573 SETSCREW
16 ST16260 2 0920054 WASHER
17 ST15903 2 ST15903 WASHER
18 UF1556 2 UF1556 SETSCREW
19 ST16260 2 0920054 WASHER
20 ST15903 2 ST15903 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 ST11612 2 ST11612 INSERT
4 ST11621 1 ST11621I INSERT
5 CV17853 2 CV17853 ADAPTOR
21 ST33617 1 ST33617 PLUG
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50281 1 OE50281 OIL PIPE
2 ST91559 1 ST91559 HOSE
3 ST46407 2 ST46407 CLIP
4 OE50282 1 OE50282 OIL PIPE
5 UF1502 1 UF1502 BOLT
6 0920053 1 0920053 WASHER
7 ST15902 1 ST15902 WASHER
8 OE48824 1 OE48824 PLUG
9 ST49853 1 ST49853 WASHER
10 ST20106 1 ST20106 PLUG
11 ST49856 1 ST49856 WASHER
12 ST91207 4 ST91207 HOSE
13 ST46408 8 ST46408 CLIP
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50194 1 OE50194 OIL PIPE
2 OE48705 1 OE48705 CONNECTION
3 ST21913 4 ST21913 SEAL - O RING
4 UF1501 1 UF1501 BOLT
5 0920053 1 0920053 WASHER
6 UF1516 2 UF1516 BOLT
7 0920053 2 0920053 WASHER
8 ST15902 2 ST15902 WASHER
9 OE48701 1 OE48701 GROOVE PIN
10 OE50154 2 OE50154 SEAL - O RING
11 OE48707 1 OE48707 BOBBIN
12 ST21914 4 ST21914 SEAL - O RING
13 OE48706 1 OE48706 HOUSING
14 OE50153 1 OE50153 SEAL - O RING
15 ST20136 1 ST20136 PLUG
16 ST49857 1 ST49857I WASHER
17 UF1516 1 UF1516 BOLT
18 0920053 1 0920053 WASHER
19 ST15902 1 ST15902 WASHER

项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49859 1 OE52696 油泵
(1) OE49859R 1 OE49859R 油泵 -交换
19 OE15060 2 OE15060 合钉
20 UF1556 2 UF1556 固定螺钉
21 0920054 2 0920054 垫圈
22 UF1565 2 UF1565 固定螺钉
23 0920054 2 0920054 垫圈
24 OE49724 1 OE49724 填隙用木片
25 OE49725 1 OE49725 填隙用木片
26 ST21919 2 ST21919 密封 - O 的圈
27 ST21913 2 ST21913 密封 - O 的圈
29 UF1502 2 UF1502 螺拴
30 ST16259 2 0920053 垫圈
31 OE50251 1 OE50251 吸入口
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OE48956 1 OE48956 BODY
4 CV5671 2 CV5671 DOWEL
5 OE48860 1 OE48860 SHAFT
6 OE48859 1 OE48859 OIL PUMP GEAR
7 OE48957 1 OE48957 COVER
9 OE49858 1 OE49858 OIL PUMP GEAR
10 OE48863 1 OE48863 PLUG
11 ST49856 1 ST49856 WASHER
12 OE48864 1 OE48864 SPRING
13 OE48862 1 OE48862 PLUNGER
14 OE49615 1 OE49615 OIL PUMP GEAR
15 UF1515 4 UF1515 BOLT
16 ST16259 4 0920053 WASHER
17 UF1516 2 UF1516 BOLT
18 ST16259 2 0920053 WASHER

项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50044/1 6 OE50044/1 活塞装备
1 OE51876/1 1 OE51876/1 活塞装备 -高度定等级
1 OE51877/1 1 OE51877/1 活塞装备 -高度定等级
5 KRP1251 6 KRP1251 活塞环装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50044/1 6 OE50044/1 PISTON KIT
1 OE51876/1 1 OE51876/1 PISTON KIT - HEIGHT GRADED
1 OE51877/1 1 OE51877/1 PISTON KIT - HEIGHT GRADED
5 KRP1251 6 KRP1251 PISTON RING KIT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE42184 12 OE42184 PUSHROD
2 OE50775 12 Check History TAPPET


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE51437 2 OE51437 汽缸盖盖
2 OE48297 2 CV67896 密合垫 -CYL。 冒口盖
3 32726535 6 32726535 螺帽
4 0920009 6 0920009 垫圈
5 33817132 6 检查历史 密封
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE51437 2 OE51437 CYLINDER HEAD COVER
2 OE48297 2 CV67896 GASKET - CYL. HEAD COVER
3 32726535 6 32726535 NUT
4 0920009 6 0920009 WASHER
5 33817132 6 Check History SEAL


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE51556 2 OE51556 摇杆桥组合
16 UF1569 12 UF1569 固定螺钉
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE51556 2 OE51556 ROCKER SHAFT ASSEMBLY
16 UF1569 12 UF1569 SETSCREW

项目 零配件号码 Qty。 最近的部分号码 描述
2 OE50459/1 1 OE50459/1 摇杆桥 ASSY-未成年人
4 OE50852 1 OE50852 托架
5 UF1502 1 UF1502 螺拴
6 ST16259 1 0920053 垫圈
7 OE52906 2 OE52906 托架
7 OE50854 2 OE52906 托架
8 OE50853 3 OE50853 图钉
9 OE52557 2 OE52557 CIRCLIP
9 KB14169 2 OE52557 CIRCLIP
10 OE431 2 OE431 垫圈
11 OE429 2 OE429I 摇杆桥弹簧
12 OE51555 6 OE51555 摇臂组合
12 OE42277 6 检查历史 摇杆
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 OE50459/1 1 OE50459/1 ROCKER SHAFT ASSY - MINOR
4 OE50852 1 OE50852 PEDESTAL
5 UF1502 1 UF1502 BOLT
6 ST16259 1 0920053 WASHER
7 OE52906 2 OE52906 PEDESTAL
7 OE50854 2 OE52906 PEDESTAL
8 OE50853 3 OE50853 STUD
9 OE52557 2 OE52557 CIRCLIP
9 KB14169 2 OE52557 CIRCLIP
10 OE431 2 OE431 WASHER
11 OE429 2 OE429I ROCKER SHAFT SPRING
12 OE51555 6 OE51555 ROCKER ARM ASSEMBLY
12 OE42277 6 Check History ROCKER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
13 OE51476 1 OE45773 ROCKER ARM BUSH
14 OE41699 1 OE41699 SCREW
15 OE42293 1 OE42293 LOCKNUT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
OE40442 14 OE40442 NUT
2 OD19995 1 OD19995 SEALING RING
3 OE50887 2 OE50887 SEAL - ROCKER BOX COVER
4 ST49206 1 ST49206 WASHER
5 OE51482 1 OE51482 GASKET
6 OE50255 1 OE50255 SEAL - REAR END OIL
7 OE50254 1 OE50254 SEAL - FRONT END OIL
8 OE50888 1 OE50888 GASKET - THERMOSTAT HSG
9 OE50899 1 OE50899 GASKET - BLANKING PLATE
10 OE51181 1 OE51181 GASKET - TIMING CASE
11 OE51175 1 OE51175 GASKET - TIMING CASE COVER
12 OE51178 1 OE51178 GASKET - SUMP
13 OE50114 1 OE50114 SEALING RING
14 ST10546 1 ST10546 SEALING RING
15 ST45105 12 ST45105 SEAL - O RING
16 ST33398 1 ST33398 DOWEL
17 OE50886 2 OE50886 GASKET
18 OE50838 4 OE50838 SEALING RING
19 OE29192 1 OE29192 ROLL PIN
20 OE3844 6 OE3844 SNAP RING
21 OE51168 1 OE51168 GASKET - BLANKING PLATE
22 ST49209 1 ST49209 WASHER
23 ST49892 4 ST49892 WASHER
24 OE50889 1 OE50889 GASKET
25 OE4421 5 OE4421 PIN
26 OE51169 1 OE51169 GASKET - WATER PUMP
27 0920113 1 0920113 WASHER
28 ST45119 6 ST45119 SEAL - O RING
29 OE51170 1 OE51170 GASKET - WATER PUMP
30 OE44678 2 OE44678 SEAL - O RING
31 OE45113/1 1 OE45113/1 LUBRICANT
32 OE51176 1 OE51176 GASKET - COMPRESSOR
33 ST45127 2 ST45127 SEAL - O RING
34 OE52244 18 OE52244 SEAL
35 OE48311 1 OE48311 SEAL - O RING
36 OE50895 1 OE50895 GASKET - OIL SEAL HOUSING
37 OE51174 1 OE51174 GASKET
38 OE51177 1 OE51177 GASKET - COMPRESSOR
39 OE50153 1 OE50153 SEAL - O RING
40 OE50154 2 OE50154 SEAL - O RING
41 OE6870 1 OE6870 PLATE
42 OE51916 1 OE51916 GASKET
43 ST10529 6 ST10529 SEAL - O RING
44 ST20606 4 ST20606 WASHER
45 ST21913 10 ST21913 SEAL - O RING
46 ST21914 14 ST21914 SEAL - O RING
47 ST21919 2 ST21919 SEAL - O RING
48 ST49851 1 ST49851 WASHER
49 ST49852 2 ST49852 WASHER
50 ST49853 4 ST49853 WASHER
51 ST49856 3 ST49856 WASHER
52 ST49857I 7 ST49857I WASHER
52 ST49857 7 ST49857I WASHER
53 ST49883 1 ST49883 WASHER
54 ST49885 2 ST49885 WASHER
55 ST49853 2 ST49853 WASHER
56 ST49891 8 ST49891 WASHER
57 ST49895 1 ST49895 WASHER
58 ST49896 1 ST49896 WASHER
59 ST49940 2 ST49940 WASHER
60 OE52092I 1 OE52092I GASKET
60 OE52092 1 OE52092I GASKET
61 OE52112 1 OE52112 GASKET - SUMP




项目 零配件号码 Qty。 最近的部分号码 描述
1 OE51839 2 OE52809 汽缸盖组合
项目 零配件号码 Qty。 最近的部分号码 描述
2 1 汽缸盖
3 OE50118 3 OE50118 嵌入内冷铁
3 OE50178 1 OE50178 嵌入内冷铁
4 OE49094 3 OE49094 嵌入内冷铁
4 OE50149 1 OE50149 嵌入内冷铁
5 OE43070 3 OE43070 阀导入
6 OE46001 3 OE46001 阀导入
7 OE50207 3 OE50207 套筒
8 OE49978 3 OE49978 封闭砂条
9 ST33602 1 ST33602 栓塞
10 ST33606 5 ST33606 栓塞
11 ST33609 5 ST33609 栓塞
12 ST33613 4 ST33613 栓塞
13 OE50588 3 OE50588 吸入口阀
14 OE42266 3 OE42266 位子
15 OE42300 3 CV68907 阀弹簧外部的
16 OE42301 3 CV68908 阀弹簧内部
17 OE30935 3 OE30935 位子
18 OE5718 3 OE5718 密封 - O 的圈
19 OE2582 6 OE2582 阀筒夹
20 OE50589 3 OE50589 排气阀
21 OE51440 3 OE51440 密封 - 阀转杆
22 OE42300 3 CV68907 阀弹簧外部的
22 OE49261 3 OE49261 阀弹簧外部的
23 OE42301 3 CV68908 阀弹簧内部
23 OE49260 3 OE49260 阀弹簧内部
24 OE30935 3 OE30935 位子
25 OE5718 3 OE5718 密封 - O 的圈
26 OE2582 6 OE2582 阀筒夹
27 OE45920 3 OE45920 密封 - 阀转杆
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 CYLINDER HEAD
3 OE50118 3 OE50118 INSERT
3 OE50178 1 OE50178 INSERT
4 OE49094 3 OE49094 INSERT
4 OE50149 1 OE50149 INSERT
5 OE43070 3 OE43070 VALVE GUIDE
6 OE46001 3 OE46001 VALVE GUIDE
7 OE50207 3 OE50207 SLEEVE
8 OE49978 3 OE49978 SEALING RING
9 ST33602 1 ST33602 PLUG
10 ST33606 5 ST33606 PLUG
11 ST33609 5 ST33609 PLUG
12 ST33613 4 ST33613 PLUG
13 OE50588 3 OE50588 INTAKE VALVE
14 OE42266 3 OE42266 SEAT
15 OE42300 3 CV68907 VALVE SPRING OUTER
16 OE42301 3 CV68908 VALVE SPRING INNER
17 OE30935 3 OE30935 SEAT
18 OE5718 3 OE5718 SEAL - O RING
19 OE2582 6 OE2582 VALVE COLLET
20 OE50589 3 OE50589 EXHAUST VALVE
21 OE51440 3 OE51440 SEAL - VALVE STEM
22 OE42300 3 CV68907 VALVE SPRING OUTER
22 OE49261 3 OE49261 VALVE SPRING OUTER
23 OE42301 3 CV68908 VALVE SPRING INNER
23 OE49260 3 OE49260 VALVE SPRING INNER
24 OE30935 3 OE30935 SEAT
25 OE5718 3 OE5718 SEAL - O RING
26 OE2582 6 OE2582 VALVE COLLET
27 OE45920 3 OE45920 SEAL - VALVE STEM


项目 零配件号码 Qty。 最近的部分号码 描述
2 OE52557 4 OE52557 CIRCLIP
3 ST11378 1 ST11378 密封
4 2413695 2 2413695 密封 - O 的圈
5 OE50899 1 OE50899 切片密合垫的板
6 OE50898 1 OE50898 密合垫
7 OE50888 1 OE50888 密合垫 - 恒温器的 HSG
8 OE50904 6 OE50904 密合垫 - IND 的岐管
9 OE51171 1 OE51171 密合垫
10 OE51170 1 OE51170 密合垫 - 水的泵
11 ST45127 2 ST45127 密封 - O 的圈
12 ST45105 12 ST45105 密封 - O 的圈
13 OE50886 1 OE50886 密合垫
14 OE45920 6 OE45920 密封 - 阀转杆
15 CV67896 2 CV67896 密合垫 -CYL。 冒口盖
16 OE51169 1 OE51169 密合垫 - 水的泵
17 ST45119 12 ST45119 密封 - O 的圈
18 OE51184I 1 OE51184I 密合垫
18 OE51184 1 OE51184I 密合垫
19 OE48311 6 OE48311 密封 - O 的圈
20 OE50891 1 OE50891 密合垫
21 OE49978 6 OE49978 封闭砂条
22 OE52105 6 OE52105 密合垫 - 排出岐管
23 OE50116 2 OE50116 密合垫 - 汽缸盖
24 OE50210 1 OE50210 密合垫
25 OE5718 12 OE5718 密封 - O 的圈
26 3311 A042 6 3311 A042 密封
27 33817135 6 33817135 密封
28 33121416 6 33121416 填隙用木片
29 ST20606 4 ST20606 垫圈
30 ST49856 1 ST49856 垫圈
31 ST49853 1 ST49853 垫圈
32 ST49938 17 ST49938 垫圈
33 OE52176 1 OE52176 密合垫
34 CV20235 1 CV20235 密合垫
35 R2411B118 6 R2411B118 垫圈

项目 零配件号码 Qty。 最近的部分号码 描述
1 KRP1261/1 1 KRP1261/1 活塞及炉衬装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 KRP1261/1 1 KRP1261/1 PISTON AND LINER KIT


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE51422 1 CV65429 起动器电动机
(1) OE51422R 1 CV65429R 起动器电动机 -交换
2 OE28471 3 OE28471 螺拴
3 ST16264 3 ST16264 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE51422 1 CV65429 STARTER MOTOR
(1) OE51422R 1 CV65429R STARTER MOTOR - EXCHANGE
2 OE28471 3 OE28471 BOLT
3 ST16264 3 ST16264 WASHER

项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50770 1 OE50770 污水坑
4 OE51178 1 OE51178 密合垫 -污水坑
5 OE43681 1 OE43681 栓塞
5 ST20105 1 ST20105 栓塞
6 OE43682 1 OE43682 嵌入内冷铁
7 OE46021 2 OE46021 销
8 OE42422 1 OE42422 垫圈
9 ST20134 1 ST20134 栓塞
10 ST49206 1 ST49206 垫圈
11 UF1558 34 UF1558 固定螺钉
12 0920054 34 0920054 垫圈
13 ST15903 34 ST15903 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50770 1 OE50770 SUMP
4 OE51178 1 OE51178 GASKET - SUMP
5 OE43681 1 OE43681 PLUG
5 ST20105 1 ST20105 PLUG
6 OE43682 1 OE43682 INSERT
7 OE46021 2 OE46021 PIN
8 OE42422 1 OE42422 WASHER
9 ST20134 1 ST20134 PLUG
10 ST49206 1 ST49206 WASHER
11 UF1558 34 UF1558 SETSCREW
12 0920054 34 0920054 WASHER
13 ST15903 34 ST15903 WASHER

项目 零配件号码 Qty。 最近的部分号码 描述
3 OE50038Z 1 OE50038Z 驾驶
7 OE52163 1 OE51168 切片密合垫的板
8 UF1452 2 UF1452 螺拴
9 ST16258 2 ST16258 垫圈
10 OE49027 1 OE49027 公制的螺帽
11 OE47834 1 OE47834 发电机
12 OE47339/2 1 OE47339/2 驾驶装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
3 OE50038Z 1 OE50038Z DRIVE
7 OE52163 1 OE51168 GASKET - BLANKING PLATE
8 UF1452 2 UF1452 BOLT
9 ST16258 2 ST16258 WASHER
10 OE49027 1 OE49027 METRIC NUT
11 OE47834 1 OE47834 GENERATOR
12 OE47339/2 1 OE47339/2 DRIVE KIT
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
4 OE50037 1 OE50037 SPINDLE
5 OE43984 1 OE43984 COUPLING
6 OE43988 1 OE43988 CIRCLIP


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50120/1 1 OE50120/1 盖
4 OE50887 1 OE50887 密封 - 摇杆的砂箱盖
5 OE42513 1 OE42513 背板
6 OE50887 1 OE50887 密封 - 摇杆的砂箱盖
7 UF1514 2 UF1514 螺拴
8 0920053 2 0920053 垫圈
9 UF1508 21 UF1508 螺拴
10 0920053 21 0920053 垫圈
11 UF1506 5 UF1506 螺拴
12 0920053 5 0920053 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50120/1 1 OE50120/1 COVER
4 OE50887 1 OE50887 SEAL - ROCKER BOX COVER
5 OE42513 1 OE42513 BACKPLATE
6 OE50887 1 OE50887 SEAL - ROCKER BOX COVER
7 UF1514 2 UF1514 BOLT
8 0920053 2 0920053 WASHER
9 UF1508 21 UF1508 BOLT
10 0920053 21 0920053 WASHER
11 UF1506 5 UF1506 BOLT
12 0920053 5 0920053 WASHER


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49342 1 OE49342 涡轮增压器
(1) OE49342R 1 OE49342R 涡轮增压器 -交换
34 OE48828 1 OE48828 砂箱夹
38 OE50210 1 OE50210 密合垫
90 26740701 1 26740701 修补装备 -涡轮增压器
91 KRP7004 1 26740754 密合垫装备
92 KRP1264 1 KRP1264 密合垫装备
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49342 1 OE49342 TURBOCHARGER
(1) OE49342R 1 OE49342R TURBOCHARGER - EXCHANGE
34 OE48828 1 OE48828 CLAMP
38 OE50210 1 OE50210 GASKET
90 26740701 1 26740701 REPAIR KIT - TURBOCHARGER
91 KRP7004 1 26740754 GASKET KIT
92 KRP1264 1 KRP1264 GASKET KIT



项目 零配件号码 Qty。 最近的部分号码 描述
2 1 壳
3 OE45316 8 25810019 固定螺钉
4 OE45412 8 26740669 锁紧垫圈
5 OE45292 1 OE45428 心
27 1 轮机壳
28 OE45418 3 26740631 板
29 26740665 6 26740665 固定螺钉
30 OE45420 4 OE45420 板夹合
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 1 HOUSING
3 OE45316 8 25810019 SETSCREW
4 OE45412 8 26740669 LOCK WASHER
5 OE45292 1 OE45428 CORE
27 1 TURBINE HOUSING
28 OE45418 3 26740631 PLATE
29 26740665 6 26740665 SETSCREW
30 OE45420 4 OE45420 PLATE CLAMPING
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
6 1 BEARING HOUSING
7 1 PLATE
8 1 O RING
9 1 SPLIT RING
10 1 THRUST BEARING
11 3 SCREW
12 2 JOURNAL BEARING
13 4 RING
14 1 HEATSHIELD
15 1 SPLIT RING
16 1 BAFFLE
17 1 RING
21 OE45429 1 OE45429 ROTOR
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50683 1 OE50683 OIL PIPE
2 ST20554 1 ST20554I ADAPTOR
3 ST49891 1 ST49891 WASHER
4 OE50898 1 OE50898 GASKET
5 ST46076 1 ST46076I PLUG
6 ST49851 1 ST49851 WASHER
7 ST43502 2 ST43502 BOLT
8 2134A008 2 2134A008 WASHER
9 OE49595 1 OE49595 OIL PIPE
10 OE50899 1 OE50899 GASKET - BLANKING PLATE
11 2314C044 2 2314C044 SETSCREW
12 2134A008 2 2134A008 WASHER
13 OE51184 1 OE51184I GASKET
14 UF1554 3 UF1554 SETSCREW
15 0920054 3 0920054 WASHER





项目 零配件号码 Qty。 最近的部分号码 描述
1 OE50588 6 OE50588 吸入口阀
2 OE42266 6 OE42266 位子
3 OE42300 6 CV68907 阀弹簧外部的
4 OE42301 6 CV68908 阀弹簧内部
5 OE30935 6 OE30935 位子
6 OE5718 6 OE5718 密封 - O 的圈
7 OE2582 12 OE2582 阀筒夹
8 OE50589 6 OE50589 排气阀
9 OE51440 6 OE51440 密封 - 阀转杆
10 OE49261 6 OE49261 阀弹簧外部的
11 OE49260 6 OE49260 阀弹簧内部
12 OE30935 6 OE30935 位子
13 OE5718 6 OE5718 密封 - O 的圈
14 OE2582 12 OE2582 阀筒夹
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50588 6 OE50588 INTAKE VALVE
2 OE42266 6 OE42266 SEAT
3 OE42300 6 CV68907 VALVE SPRING OUTER
4 OE42301 6 CV68908 VALVE SPRING INNER
5 OE30935 6 OE30935 SEAT
6 OE5718 6 OE5718 SEAL - O RING
7 OE2582 12 OE2582 VALVE COLLET
8 OE50589 6 OE50589 EXHAUST VALVE
9 OE51440 6 OE51440 SEAL - VALVE STEM
10 OE49261 6 OE49261 VALVE SPRING OUTER
11 OE49260 6 OE49260 VALVE SPRING INNER
12 OE30935 6 OE30935 SEAT
13 OE5718 6 OE5718 SEAL - O RING
14 OE2582 12 OE2582 VALVE COLLET


项目 零配件号码 Qty。 最近的部分号码 描述
1 OE49778/1 1 检查历史 时间安排箱
8 OE51181 1 OE51181 密合垫 - 时间安排的箱
9 OE50254 1 OE50254 密封 -前面端油
10 UF1504 1 UF1504 螺拴
11 ST16259 1 0920053 垫圈
12 ST15902 1 ST15902 垫圈
13 UF1518 2 UF1518 螺拴
14 UF4354 2 UF4354 螺帽
15 ST16259 2 0920053 垫圈
16 ST15902 2 ST15902 垫圈
17 ST26439 1 ST26439 螺拴
18 OE23642 1 OE23642 锁紧螺母
19 OE48475 1 OE48475 垫圈
20 UF1612 3 UF1612 固定螺钉
21 ST20608 3 ST20608 垫圈
22 UF1507 2 UF1507 螺拴
23 ST16259 2 0920053 垫圈
24 ST15902 2 ST15902 垫圈
25 UF1509 1 UF1509 螺拴
26 UF4354 1 UF4354 螺帽
27 ST15902 1 ST15902 垫圈
28 ST16259 1 0920053 垫圈
29 UF1556 1 UF1556 固定螺钉
30 ST16260 1 0920054 垫圈
31 ST15903 1 ST15903 垫圈
32 UF1563 5 UF1563 固定螺钉
33 ST16260 5 0920054 垫圈
34 ST15903 5 ST15903 垫圈
35 UF1520 1 UF1520 螺拴
36 ST16259 1 0920053 垫圈
37 ST15902 1 ST15902 垫圈
38 UF1517 1 UF1517 螺拴
39 ST16259 1 0920053 垫圈
40 ST15902 1 ST15902 垫圈
42 UF1503 2 UF1503 螺拴
43 ST16259 2 0920053 垫圈
44 ST15902 2 ST15902 垫圈
45 UF1518 1 UF1518 螺拴
46 ST16259 1 0920053 垫圈
47 ST15902 1 ST15902 垫圈
51 OE49627 1 OE49627 盖
53 OE51175 1 OE51175 密合垫 - 时间安排的箱盖
54 OE44004 1 OE44004 堵塞盖
55 OE51168 1 OE51168 切片密合垫的板
56 UF1451 2 UF1451 螺拴
57 ST16258 2 ST16258 垫圈
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE49778/1 1 Check History TIMING CASE
8 OE51181 1 OE51181 GASKET - TIMING CASE
9 OE50254 1 OE50254 SEAL - FRONT END OIL
10 UF1504 1 UF1504 BOLT
11 ST16259 1 0920053 WASHER
12 ST15902 1 ST15902 WASHER
13 UF1518 2 UF1518 BOLT
14 UF4354 2 UF4354 NUT
15 ST16259 2 0920053 WASHER
16 ST15902 2 ST15902 WASHER
17 ST26439 1 ST26439 BOLT
18 OE23642 1 OE23642 LOCKNUT
19 OE48475 1 OE48475 WASHER
20 UF1612 3 UF1612 SETSCREW
21 ST20608 3 ST20608 WASHER
22 UF1507 2 UF1507 BOLT
23 ST16259 2 0920053 WASHER
24 ST15902 2 ST15902 WASHER
25 UF1509 1 UF1509 BOLT
26 UF4354 1 UF4354 NUT
27 ST15902 1 ST15902 WASHER
28 ST16259 1 0920053 WASHER
29 UF1556 1 UF1556 SETSCREW
30 ST16260 1 0920054 WASHER
31 ST15903 1 ST15903 WASHER
32 UF1563 5 UF1563 SETSCREW
33 ST16260 5 0920054 WASHER
34 ST15903 5 ST15903 WASHER
35 UF1520 1 UF1520 BOLT
36 ST16259 1 0920053 WASHER
37 ST15902 1 ST15902 WASHER
38 UF1517 1 UF1517 BOLT
39 ST16259 1 0920053 WASHER
40 ST15902 1 ST15902 WASHER
42 UF1503 2 UF1503 BOLT
43 ST16259 2 0920053 WASHER
44 ST15902 2 ST15902 WASHER
45 UF1518 1 UF1518 BOLT
46 ST16259 1 0920053 WASHER
47 ST15902 1 ST15902 WASHER
51 OE49627 1 OE49627 COVER
53 OE51175 1 OE51175 GASKET - TIMING CASE COVER
54 OE44004 1 OE44004 BLANKING COVER
55 OE51168 1 OE51168 GASKET - BLANKING PLATE
56 UF1451 2 UF1451 BOLT
57 ST16258 2 ST16258 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
1 OE50627 1 Check History BACKPLATE
7 OE49028 1 OE49028 SLEEVE
8 OE49005 1 OE51174 GASKET
10 ST10546 1 ST10546 SEALING RING
11 OE49031 2 OE49031 DOWEL
12 UF1604 2 UF1604 SETSCREW
13 0920055 2 0920055 WASHER
14 ST15904 2 ST15904 WASHER
15 UF1607 1 UF1607 SETSCREW
16 0920055 1 0920055 WASHER
17 ST15904 1 ST15904 WASHER
Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment
2 ST11611 7 ST11611 INSERT
3 ST11621 2 ST11621I INSERT
4 ST11622 6 ST11622 INSERT
5 ST45006 1 ST45006 PLUG
6 ST45007 1 ST45007 PLUG
