十堰强鹿大修包RE524593厂家供应

约翰迪尔 6068T/H 6.8T/H 活塞(米)RE527039 排放 2 & 3 Power Tech 6068T/H 6.8T/H 活塞(米)RE527039, PowerTech 系列 发动机和设备型号 6068T/H 排放2&3 每缸2个气门 代码4839 6缸数 孔径: 4.19in106.5mm 销径Ø: 1.6250in(+/-.0002)=41mm 发动机型号: 6068HT069 连杆(米): R500335(Fractured)(9) 连杆(米): RE527039 洋马发动机 农业 1450CWS 6630 1450WTS 6830 1470 6930 1550CWS 7130 1550WTS 7230
产品咨询

详细描述

约翰迪尔收割机应用的发动机零件

设备型号 备注
1270D High Compression Piston. To ESN 199,999. Tier 1
703JH 9.0 Liter Tier 2 & Tier 3
1470D High Compression Piston. To ESN 199,999. Tier 1
753JH 9.0 Liter Tier 2 & Tier 3
753 GL High Compression Piston. To ESN 199,999. Tier 1
759J 9.0 Liter Tier 2 & Tier 3
703JH High Compression Piston. From ESN 200,000. Tier 2.
759JH 9.0 Liter Tier 2 & Tier 3
853JH Low Compression Piston. From ESN 200,000. Tier 2.
909KH 9.0 Liter Tier 2 & Tier 3
903JH Low Compression Piston. From ESN 200,000. Tier 2.
1270G 9.0 Liter Tier 2 & Tier 3
909JH Low Compression Piston. From ESN 200,000. Tier 2.
1470G 9.0 Liter Tier 2 & Tier 3
1270D 9.0 Liter Tier 2 & Tier 3
959K 9.0 Liter Tier 2 & Tier 3
1270E 9.0 Liter Tier 2 & Tier 3
1470D 9.0 Liter Tier 2 & Tier 3
1470E 9.0 Liter Tier 2 & Tier 3

约翰迪尔 6068T/H 6.8T/H 活塞(米)RE527039 排放 2 & 3


PowerTech
系列
发动机和设备型号
6068T/H
排放 2 & 3

每缸2个气门

代码 4839

孔径:
4.19 in 106.5 mm

销径 Ø:
1.6250 in (+/- .0002) = 41mm

发动机型号:

6068HT069

连杆(米):
R500335 (Fractured) (9)
连杆(米):
RE527039

洋马发动机

农业
1450CWS
6630
1450WTS
6830
1470
6930
1550CWS
7130
1550WTS
7230
1654
7330
1854
7430
2054
W330
6225
6525
6530
AKSA
APD-AGJ150
APD-AGJ180
APD-AT150
APD-AT180
APD-EPAJ150
APD-EPAJ180
APD-ULJ150
APD-ULJ180
工程机械
710K
HI POWER GENSET
HJW 155 T6
HRJW 175 T6
发电机组
R165C3
1)
发动机大修包
TRE532634
(点击查看套件内容)
2)
发动机内部修理套件
TIK532634
(点击查看套件内容)
活塞缸套组件
TRE536083
组成:
a)
TRE527039
b)
TRE527844
c)
TR502755
d)
TR116397
e)
TAR65507
f)
TR54114
主轴瓦
TRE65165
Std.
TRE65911
0.010
TRE65165B
0.020
(8)
需要6片
止推轴承
TRE65168
Std.
TRE65912
0.010
TRE65168B
0.020
(8)
需要1片
连杆瓦
TRE65908
Std.
TRE65909
0.010
TRE65908B
0.020
(8)
需要6片
1)
前油封
TRE505515
(1)
2)
后油封
TRE44574
3)
齿环
TR114282
(5)
TR28811
(5)
4)
曲轴
TRE515785
(3)
TRE505921
(4)
1)
密封圈维修包
TRE532631
2)
衬垫套
TRE532841
3)
气缸垫
TR116516
4)
机油底壳垫圈
TR521498
(5)
TR123354
(5)
5)
气门室盖衬垫
TR524469
1)
连杆衬套
TR114082
x6
2)
连杆螺栓
TR501124
x12
3)
凸轮轴衬套
TR119874
x1
4)
凸轮随动件
TR123565
x12
1)
气缸盖螺钉
TR502511
x26
(5)
TR85363
x26
(5)
2)
紧张轮
TRE518097
(5)
TRE68715
(5)
3)
连杆
TRE500608
4)
机油冷却器
TRE59296
(5 板)
TRE56690
(7 板)
TRE59298
(9 板)
1)
水泵
TRE500734
(5)
(高流量)
2)
水泵盖
TRE508566
3)
水泵衬垫
TR123417
4)
凸轮轴衬套
TRE504914

阀门部分

进气门
TR98062
Std.
TR97490
0.015
排气门
TR90692
Std.
TR97492
0.015
1)
插入阀:进气
TR106831
Std.
2)
插入阀:排气
TR106829
Std.
1)
气门密封
TRE31617
2)
气门锁夹
TR91889
1)
弹簧阀
TR26125
(5)
2)
旋转阀
TRE60005
(5)
1)
节温器
TRE522076
180° F
(5)
TRE528652
180o F
(5)
TRE540550
180° F
(5)
TRE64354
180° F
(5)
2)
节温器盖
TR501130
(5)
3)
水温传感器
TRE51774
(5)
4)
水温传感器
TRE52722
(5)
5)
油压传感器
TRE167207
(5)
6)
曲轴传感器
TRE519144
(5)
7)
燃油压力传感器
TRE522794
(5)
8)
温度感应器
TRE522823
(5)
输油泵
TRE66153
(5) (6)
TRE68345
(5) (7)
TRE502513
(5) (8)
火花塞
1)
TRE502079
(11 V)
2)
TRE504580
x6
(10 V)
3)
空气加热器
TRE502668
(12 V)

(1)1件组合式密封和穿套; 替换TRE59810,RE538097。

(2)在曲轴加工过程中必须保持正确的轴承轴颈半径,以确保正确操作。

(3)曲轴(m)R116076,直鼻。

(4)曲轴(m)R503470,锥形鼻。

(5)检查应用程序是否正确使用。

(6)线路连接都是线程化的。

(7)线路连接是一个软管倒钩& 一个线程。

(8)线路连接是两个软管倒钩。

(9)机器分体式和断裂式分体式连杆均可用于同一台发动机,但每个连杆必须使用正确的连杆螺栓。

美国强鹿JOHN DEERE柴油发电机配件及发动机配件:
CD3029DF128、CD4039DF008、CD4045TF258、PE4045、CD6068TF158、CD6068TF258、CD6068HF158、CD6068HF258、CD6081HF001A、4045TFM75、CD6081HF001B、CD6125HF070A、CD6125HF070B、RG6125、6135H458。4045DFM70, 4045TFM75, 6068TFM75, 6068TFM76、4039DFM RE522528、RE519774、RE532628、RE518176、RE507980、RE518503、RE522515、RE504836、RE509031powertech? 8.1 l diesel engines — base engine 032001 pn=456 repair&general oem specifications 06 200 27 dpsg,ouo1004,850 –19–27apr99–1/3 group 070 — cooling system repair specifications item measurement specification adjustable fan drive housing id 71.999—72.025 mm (2.8346—2.8356 in.) adjustable fan drive shaft od 35.001—35.017 mm (1.3780—1.3786 in.) adjustable fan drive bearing id. 34.987—35.013 mm (1.3774—1.3785 in.) od 71.987—72.013 mm (2.8341—2.8351 in.) adjustable fan drive shaft end play 0.10 mm (0.004 in.) adjustable fan drive housing seal depth flush-to-0.50 mm (0.020 in.) below housing face fan/hub pulley-to-fan spacer cap torque 60 n?m (45 lb-ft) screws fan hub/pulley-to-fan shaft torque 80 n?m (60 lb-ft) fan drive support plate-to-engine 5/16-in. mounting cap screws (to torque 24 n?m (18 lb-ft) injection pump access cover) 5/16-in. mounting cap screws (all torque 35 n?m (26 lb-ft) others) 3/8-in. mounting cap screws torque 61 n?m (45 lb-ft) 1/2-in. mounting cap screws torque 101 n?m (74 lb-ft) coolant manifold-mounted fixed fan drive specifications fixed fan drive shaft od 25.387—25.400 mm (0.9995—1.0000 in.) fixed fan drive bearing od 47.612—47.625 mm (1.8745—1.8750 in.) ctm86 (20mar01) 06-200-27 powertech? 8.1 l diesel engines — base engine 032001 pn=457 continued on next page repair&general oem specifications 06 200 28 dpsg,ouo1004,850 –19–27apr99–2/3 item measurement specification fixed fan drive pulley (bearing id 47.576—47.612 mm end) (1.8731—1.8745 in.) fixed fan drive pulley (fan id 49.485—49.518 mm spacer end )1 (1.9482—1.9495 in.) fan spacer1 o.d. 49.457—49.483 mm (1.9471—1.9481 in.) fixed fan drive manifold i.d. 25.336—25.362 mm (0.9975—0.9985 in.) fixed fan drive shaft (installed) dimension from manifold mounting 32.51—32.77 mm face to end of shaft (1.280—1.290 in.) adjustable fan drive housing seal depth flush-to-0.50 mm (0.020 in.) below housing face fixed fan drive bearing shaft depth 33.31—33.57 mm (1.311—1.322 in.) below manifold mounting surface fixed fan drive (coolant manifold torque 60 n?m 45 (lb-ft) mounted) cap screws belt tensioner spring tension 24-28 n?m (17-21 lb-ft) fan-to-fan hub/pulley torque 47 n?m (35 lb-ft) coolant pump cover mounting cap screws 5/16-in. mounting cap screws torque 27 n?m (20 lb-ft) 3/8-in. cap screws torque 47 n?m (35 lb-ft) thermostat 82°c (180°f) opening temperature 80—84°c (175—182°f) cast iron thermostat torque 47 n?m (35 lb-ft) cover-to-cylinder head 1units with press-fit fan spacer only. ctm86 (20mar01) 06-200-28 powertech? 8.1 l diesel engines — base engine 032001 pn=458 continued on next page repair&general oem specifications dpsg,ouo1004,850 –19–27apr99–3/3 item measurement specification aluminum thermostat torque 30 n?m (22 lb-ft) cover-to-cylinder head coolant manifold-to-cylinder head torque 35 n?m (25 lb-ft) cap screws coolant temperature switch torque 45 n?m (33 lb-ft) 06 200 29 dpsg,ouo1004,853 –19–28apr99–1/1 group 080 — air intake&exhaust system repair specifications item measurement specification turbocharger shaft radial bearing clearance (allowable 0.13—0.18 mm (0.005—0.007 in.) movement) turbocharger shaft axial bearing end play 0.064—0.114 mm (0.0025—0.0045 in.) turbocharger wastegate actuator end play 0.05—0.056 mm (0.002-0.022 in.) turbocharger-to-exhaust manifold torque 24 n?m (18 lb-ft) cap screws turbocharger oil return line torque 34 n?m (25 lb-ft) exhaust manifold-to-cylinder head torque 80 n?m (60 lb-ft) cap screws (6081hrw engines) exhaust manifold-to-cylinder head torque 47 n?m (35 lb-ft) cap screws (all other engines) intake manifold-to-cylinder head torque 47 n?m (35 lb-ft) aftercooler cover-to-intake manifold torque 34 n?m (25 lb-ft) aftercooler cover-to-intake manifold torque 34 n?m (25 lb-ft) aftercooler assembly-to-cylinder torque 47 n?m (35 lb-ft) head ctm86 (20mar01) 06-200-29 powertech? 8.1 l diesel engines — base engine 032001 pn=459 repair&general oem specifications 06 200 30 dpsg,ouo1004,858 –19–28apr99–1/1 group 100 — oem starting&charging systems repair specifications item measurement specification alternator mounting hardware torque 27 n?m (20 lb-ft) (upper) alternator mounting hardware torque 80 n?m (60 lb-ft) (lower) alternator mounting bracket and strap hardware alternator adjusting torque 35 n?m (26 lb-ft) strap-to-thermostat housing (7/8 in. long) cap screws alternator adjusting torque 61 n?m (45 lb-ft) strap-to-thermostat housing (2 in. long) cap screws alternator front torque 61 n?m (45 lb-ft) support-to-alternator rear support (1-3/4 in. long) cap screws alternator bracket-to-alternator torque 35 n?m (26 lb-ft) support (1 in.&1-1/4 in. long) cap screws alternator support-to-thermostat torque 61 n?m (45 lb-ft) housing (1 in.&1-1/4 in. long) cap screws starter motor mounting hardware torque 44 n?m (33 lb-ft)崇左JohnDeere连杆铜衬套R74008找哪家,太原强鹿柴油机曲轴后油封RE53687哪家好,湘西约翰迪尔8R-2904拖拉机发动机配件诚信推荐,永州JohnDeere进气门供货商,吕梁JohnDeere左平衡轴TRE500449市场报价,汉中美国强鹿发动机配件ECURE532628一级代理,攀枝花强鹿履带式推土机柴油机配件价格行情,白山强鹿柴油机废气热交换器RE521493多少钱,丹东美国强鹿发电机大修包厂家供货,岳阳强鹿AR65507阻水圈代理,阿坝强鹿水泵O型圈TRE509463厂家批发,平顶山约翰迪尔柴油机活塞缸套组件TRE520768的价格,黄南约翰迪尔强鹿进气门R520223厂家供货, (upper) starter motor mounting hardware torque 27 n?m (20 lb-ft) (lower) ctm86 (20mar01) 06-200-30 powertech? 8.1 l diesel engines — base engine 032001 pn=460 group 210 diagnostic specifications 06 210 1 dpsg,rg40854,702 –19–02aug00–1/2 group 150 — base engine diagnostic specifications (includes dynamometer specifications (oem)&turbocharger boost specifications) engine compression pressure note: pressure given was taken at 300 m (1000 ft) above seal level. a 3.6% reduction in gauge pressure will result for each additional 300 m (1000 ft) above sea level. specification engine compression pressure—compression pressure 2,380—2,790 kpa (23.8—27.9 bar) (345—405 psi)    all cylinders within engine should have approximately the same pressure. there should be less than 340 kpa (3.4?bar) (50 psi) difference between cylinders. oil pressure specification oil pressure specifications—minimum no load at 850 rpm (slow idle)    138 kpa (1.38 bar) (20 psi) maximum full load at 2200 rpm (rated speed)    400 kpa (4.0 bar) (58 psi) turbocharger wastegate actuator note: the specifications below are the air pressures required to move the actuator on the wastegate. turbocharger wastegate actuator pressure specification engine model number pressure applied to actuator 6081at001 144.28 kpa (14.4 bar) (20.92 psi) 6081hdw04 144.28 kpa (14.4 bar) (20.92 psi) 6081hdw05 144.28 kpa (14.4 bar) (20.92 psi) 6081hdw01 184.83 kpa (18.5 bar) (26.8 psi) 6081ht001 193.10 kpa (19.3 bar) (28.0 psi) ctm86 (20mar01) 06-210-1 powertech? 8.1 l diesel engines — base engine 032001 pn=461 continued on next page diagnostic specifications dpsg,rg40854,702 –19–02aug00–2/2 thermostat thermostat test specifications rating initial opening full open (range) (nominal) 71°c (160°f) 69—72°c (156—162°f) 84°c (182°f) 77°c (170°f) 74—78°c (166—172°f) 89°c (192°f) 82°c (180°f) 80—84°c (175—182°f) 94°c (202°f) 89°c (192°f) 86—90°c (187—194°f) 101°c (214°f) 90°c (195°f) 89—93°c (192—199°f) 103°c (218°f) 92°c (197°f) 89—93°c (193—200°f) 105°c (221°f) 96°c (205°f) 94—97°c (201—207°f) 100°c (213°f) 99°c (210°f) 96—100°c (205—212°f) 111°c (232°f) 06 210 2 rg41183,000002a –19–09feb01–1/5 dynamometer test specifications power ratings for various injection pump options are provided for oem applications on the charts that follow. for construction equipment applications, refer to sp458 specifications handbook. for north american agricultural applications, refer to db1216 specifications handbook. note: the power specifications shown apply to waterloo-built oem engines. specifications are subject to change. refer to factory dtac for assistance. engine speeds listed are as preset to factory specification. in most cases, slow idle speed will be reset depending upon specific vehicle application requirements. refer to your machine technical manual for engine speeds that are different from those preset at the factory. power ratings specify flywheel power without fan or acces***ies such as air compres***. if specifications are not listed in handbooks, refer to factory dtac for assistance. ctm86 (20mar01) 06-210-2 powertech? 8.1 l diesel engines — base engine 032001 pn=462 continued on next page diagnostic specifications 06 210 3 rg41183,000002a –19–09feb01–2/5 power ratings on dynamometer for oem engines1 engine model injection injection injection governor rated speed2 fast idle3 power rating pump option pump (part pump regulation (rpm) (rpm) kw (bhp) code no.) supplier 6081af001 1601 re502438 bosch std 2200 2420 149 (200) 1602 re502438 bosch std 2200 2420 149 (200) 1603 re66449 bosch 3-5% 1500 1575 182 (244) 1604 re66456 bosch 3-5% 1500 1575 182 (244) 1605 re66456 bosch 3-5% 1500 1575 182 (244) 1606 re502439 bosch std 2200 2420 149 (200) 1607 re66450 bosch 3-5% 1500 1575 219 (292) 1608 re66457 bosch 3-5% 1500 1575 219 (292) 1609 re66457 bosch 3-5% 1500 1575 219 (293) 1610 re62642 bosch std 2200 2420 187 (250) 1611 re66243 bosch std 2200 2420 205 (275) 1612 re62644 bosch 3-5% 1800 1890 205 (275) 1613 re501785 bosch std 2200 2420 205 (275)4 1615 re501785 bosch std 2200 2420 205 (275)4 1616 re503346 bosch electronic 2200 2420 159 (213)4 2200 2420 187 (250)4 1617 re66244 bosch std 2200 2420 168 (225)4 2200 2420 205 (275) 1618 re63766 bosch std 2200 2420 187 (250) 1619 re63767 bosch 3-5% 1800 1870 168 (225) 2200 2420 205 (275) 1620 re501786 bosch std 2200 2420 205 (275)4 1621 re503345 bosch electronic 2200 2420 175 (235)4 2200 2420 205 (275)4 1622 re64162 bosch 3-5% 1800 1890 224 (300) 1623 re64214 bosch 3-5% 1800 1890 224 (300) 1624 re64214 bosch 3-5% 1800 1890 224 (300) 1632 re503346 bosch electronic 2200 2420 187 (250)4 1633 re503348 bosch electronic 2200 2420 205 (275)4 1634 re503346 bosch electronic 2200 2420 187 (250)4 1635 re503348 bosch electronic 2200 2420 205 (2754) 1640 re62642 bosch std 2200 2420 187 (250)4 1641 re503346 bosch electronic 2200 2420 187 (250)4 1642 re503348 bosch electronic 2200 2420 205 (275)4 1643 re503346 bosch electronic 2200 2420 187 (250)4 1644 re503346 bosch electronic 2200 2420 205 (275)4 1645 re503346 bosch electronic 2200 2420 187 (250)4 1646 re503346 bosch electronic 2200 2420 187 (250)4 1647 re503346 bosch electronic 2200 2420 187 (250)4 1648 re503346 bosch electronic 2200 2420 187 (250)4 1649 re503346 bosch electronic 2200 2420 187 (250)4 1650 re503346 bosch electronic 2200 2420 187 (250)4 1651 re503348 bosch electronic 2200 2420 205 (275)4 ctm86 (20mar01) 06-210-3 powertech? 8.1 l diesel engines — base engine 032001 pn=463 continued on next page diagnostic specifications 06 210 4 rg41183,000002a –19–09feb01–3/5 power ratings on dynamometer for oem engines1 engine model injection injection injection governor rated speed2 fast idle3 power rating pump option pump (part pump regulation (rpm) (rpm) kw (bhp) code no.) supplier 1652 re503348 bosch electronic 2200 2420 205 (275)4 1653 re503348 bosch electronic 2200 2420 205 (275)4 1654 re503348 bosch electronic 2200 2420 205 (275)4 1655 re503348 bosch electronic 2200 2420 205 (275)4 1656 re503348 bosch electronic 2200 2420 168 (225)4 2200 2420 205 (275) 1657 re66243 bosch electronic 2200 2420 205 (275)4 1658 re503348 bosch electronic 2200 2420 205 (275)4 1659 re503348 bosch electronic 2200 2420 205 (275)4 1660 re503175 bosch electronic 2200 2420 187 (250)4 1661 re503346 bosch electronic 2200 2420 187 (250) 1662 re503346 bosch electronic 2200 2420 187 (250) 1663 re503346 bosch electronic 2200 2420 187 (250) 1664 re503346 bosch electronic 2200 2420 187 (250) 1665 re503346 bosch electronic 2200 2420 187 (250) 1666 re503346 bosch electronic 2200 2420 187 (250) 1667 re503346 bosch electronic 2200 2420 205 (275) 1668 re503348 bosch electronic 2200 2420 205 (275) 1669 re503348 bosch electronic 2200 2420 205 (275) 1670 re503348 bosch electronic 2200 2420 205 (275) 1671 re503348 bosch electronic 2200 2420 205 (275) 1672 re503348 bosch electronic 2200 2420 205 (275) 1673 re506419 motorpal std 2200 2420 168 (225) 1674 re506419 motorpal std 2200 2420 168 (225) 1676 re62644 bosch 3-5% 1800 1890 187 (250) 2200 2420 205 (275) 1681 re502806 bosch std 2100 2320 205 (275) 1682 re503822 bosch 3-5% 1700 1890 258 (344) 1683 re503822 bosch 3-5% 1700 1890 258 (344) 1684 re503823 bosch 3-5% 1700 1890 258 (344) 1685 re505672 bosch 3-5% 1500 1560 225 (300) 1686 re505672 bosch 3-5% 1500 1560 225 (300) 1687 re503823 bosch 3-5% 1500 1560 225 (300) 1688 re506543 bosch std 2200 2420 205 (273) 6081hf001 1601 re62686 bosch std 2200 2420 224 (300)4 1602 re62686 bosch std 2200 2420 224 (300)4 1603 re62687 bosch 3-5% 1800 1890 240 (320) 1604 re62687 bosch 3-5% 1800 1890 240 (320) 1605 re63769 bosch std 2200 2420 224 (300)4 1606 re63770 bosch 3-5% 1800 1890 240 (320) 1621 re503345 bosch electronic 2200 2420 190 (255)4 2200 2420 224 (300)4 1622 re66458 bosch 3-5% 1500 1575 200 (267) 1623 re66458 bosch 3-5% 1500 1575 200 (267) ctm86 (20mar01) 06-210-4 powertech? 8.1 l diesel engines — base engine 032001 pn=464 continued on next page diagnostic specifications 06 210 5 rg41183,000002a –19–09feb01–4/5 power ratings on dynamometer for oem engines1 engine model injection injection injection governor rated speed2 fast idle3 power rating pump option pump (part pump regulation (rpm) (rpm) kw (bhp) code no.) supplier 1624 re66451 bosch 3-5% 1500 1560 200 (267) 1500 1560 245 (328) 1633 re503345 bosch electronic 2200 2420 224 (300)4 1639 re503345 bosch electronic 2200 2420 224 (300)4 1640 re503345 bosch electronic 2200 2420 224 (300)4 1641 re503345 bosch electronic 2100 2420 224 (300)4 1642 re503345 bosch electronic 2100 2420 224 (300)4 1643 re503345 bosch electronic 2100 2420 224 (300)4 1644 re503345 bosch electronic 2100 2420 224 (300)4 1645 re503345 bosch electronic 2100 2420 224 (300)4 1646 re503345 bosch electronic 2100 2420 224 (300)4 1647 re503345 bosch electronic 2100 2420 224 (300)4 1648 re503345 bosch electronic 2100 2420 224 (300)4 1661 re503812 bosch 3-5% 1500 1575 255 (342) 1662 re503812 bosch 3-5% 1500 1575 255 (342) 1663 re503813 bosch 3-5% 1500 1575 255 (342) 1680 re501861 bosch std 2100 2320 224 (300) 1681 re505670 bosch 3-5% 1800 1890 263 (353) 1682 re505670 bosch 3-5% 1800 1890 263 (353) 1683 re505475 bosch 3-5% 1800 1890 263 (353) 1684 re503812 bosch 3-5% 1500 1575 268 (357) 1685 re505670 bosch 3-5% 1500 1575 225 (302) 1686 re503812 bosch 3-5% 1500 1575 268 (359) 1687 re505670 bosch 3-5% 1800 1890 308 (413) 1688 re503345 bosch electronic 2200 2420 224 (300) 1689 re503345 bosch electronic 2200 2420 224 (300) 1690 re503345 bosch electronic 2200 2420 224 (300) 1691 re503345 bosch electronic 2200 2420 224 (300) 1692 re503345 bosch electronic 2200 2420 224 (300) 1693 re503345 bosch electronic 2200 2420 224 (300) 6081tf001 1601 re66241 bosch std 2200 2420 149 (200) 1602 re66241 bosch std 2200 2420 149 (200) 1603 re62837 denso 3-5% 1800 1890 157 (210) 1604 re62837 denso 3-5% 1800 1890 157 (210) 1605 re66242 bosch std 2200 2420 157 (210) 1606 re63750 denso 3-5% 1800 1890 157 (210) 2200 2420 149 (200) 1608 re66459 denso 3-5% 1500 1575 131 (175) 1500 1575 187 (250) 1609 re66459 denso 3-5% 1500 1575 131 (175) 1500 1575 187 (250) 1610 re66448 denso 3-5% 1500 1575 131 (175) 1611 re501016 denso std 2200 2420 128 (171) 2200 2420 168 (225) ctm86 (20mar01) 06-210-5 powertech? 8.1 l diesel engines — base engine 032001 pn=465 continued on next page diagnostic specifications 06 210 6 rg41183,000002a –19–09feb01–5/5 power ratings on dynamometer for oem engines1 engine model injection injection injection governor rated speed2 fast idle3 power rating pump option pump (part pump regulation (rpm) (rpm) kw (bhp) code no.) supplier 1612 re501016 denso std 2200 2420 128 (171) 1613 re501198 denso std 2200 2420 128 (171) 1614 re505268 bosch 3-5% 1800 1890 194 (260) 1615 re505268 bosch 3-5% 1800 1890 194 (260) 1616 re505269 bosch 3-5% 1800 1890 194 (260) 1617 re506416 motorpal std 2200 2420 149 (200) 1618 re506416 motorpal std 2200 2420 149 (200) 1619 re505486 bosch 3-5% 1500 1575 169 (227) 1620 re505671 bosch 3-5% 1500 1575 169 (227) 1621 re505671 bosch 3-5% 1500 1575 169 (227) 6081hf070 166a re501640 denso hpcr 2200 2350 242 (325)4 166b re508233 denso hpcr 2200 2350 242 (325)4 166c re501640 denso hpcr 2200 2350 242 (325)4 166d re508233 denso hpcr 2200 2350 242 (325)4 166e re501640 denso hpcr 2200 2350 242 (325)4 166f re508233 denso hpcr 2200 2350 242 (325)4 166g re501640 denso hpcr 2200 2350 242 (325)4 166h re508233 denso hpcr 2200 2350 242 (325)4 16ga re501640 denso hpcr 1000 1800 259 (347) 16gb re508233 denso hpcr 1800 1800 259 (347) 16gc re501640 denso hpcr 1800 1800 259 (347) 16gd re508233 denso hpcr 1800 1800 259 (347) 16ja re501640 denso hpcr 1800 1800 308 (413) 16jb re508233 denso hpcr 1800 1800 308 (413) 16jc re501640 denso hpcr 1800 1800 308 (413) 16jd re508233 denso hpcr 1800 1800 308 (413) 1 engine speeds listed are preset to factory specification for application. therefore, speeds may vary depending upon specific vehicle application requirements. refer to your machine operator’s manual for engine speeds that are different from those preset at the factory. 2 generator set engines (3-5% governor) usually run at 1500 rpm (50 hz)/1800 (60 hz) when operating under load depending on cycles of ac current. 3 for engines with standard governor, fast idle is 7-10% above rated speed. for engines with generator set governors, fast idle is 3-5% above rated speed. 4 these engines have a 7% power bulge which allows for intermittent operation of 7% above rated power. ctm86 (20mar01) 06-210-6 powertech? 8.1 l diesel engines — base engine 032001 pn=466 diagnostic specifications 06 210 7 dpsg,ouo1004,290 –19–23jul98–1/8 intake manifold pressure (turbocharger boost) specifications turbo boost pressures (john deere agricultural equipment) machine model engine model injection pump rated power full load turbo boost pressure at full load part # at full load rated speed rated speed rated speed rpm kpa (bar) (psi) kw (hp) des moines 9976 cotton picker rg6081hn001 re61658 219 (294) 2200 183—200 kpa (1.83—2.00 bar) (26—29 psi) rg6081hn003 re501867 240 (321) 2200 200—245 kpa (2.00—2.45 bar) (29—36 psi) 9970 cotton picker rg6081an001 re500742 187 (251) 2200 n/aa harvester 9510 low power rg6081hh001 re62645 167 (223) 2200 106—130 kpa (1.06—1.30 bar) (15—19 combine psi) re61658 207 (278) 2200 184—226 kpa (1.84—2.26 bar) (26—33 psi) 9510 high power rg6081hh002 re62645 182 (244) 2200 122—150 kpa (1.22—1.50 bar) (17—22 combine psi) 9610 rg6081hh003 re61658 206 (276) 2200 136—167 kpa (1.36—1.67 bar) (19—25 /ctsii/ctsiie(98) psi) combine re62645 187 (251) 2200 149—183 kpa (1.49—1.83 bar) (21—27 psi) ctsiie(99) rg6081hh004 re501867 240 (321) 2200 203—249 kpa (2.03—2.49 bar) (29—36 psi) re61658 240 (321) 2200 183—225 kpa (1.83—2.25 bar) (27—33 psi) 9750sts combine rg6081hh005 re501867 240 (321) 2200 197—241 kpa (1.97—2.41 bar) (29—35 psi) 9650sts combine rg6081hh006 re61658 224 (300) 2200 158—194 kpa (1.58—1.94 bar) (23—28 psi) amadus peanut rg6081hh007 re62645 181 (243) 2200 124—152 kpa (1.24—1.52 bar) (18—22 combine psi) 9550 low power rg6081hh008 re503876 173 (232) 2200 171—211 kpa (1.71—2.11 bar) (25—31 combine psi) re503347 173 (232) 2200 171—211 kpa (1.71—2.11 bar) (25—31 psi) 9550 high power rg6081hh009 n/aa 183 (245) 2200 122—150 kpa (1.22—1.50 bar) (18—22 combine psi) 9650 combine rg6081hh010 re503345 210 (281) 2200 172—211 kpa (1.72—2.11 bar) (25—31 bar) re61658 210 (281) 2200 136—167 kpa (1.36—1.67 bar) (20—24 psi) an/a = not available at time of publication ctm86 (20mar01) 06-210-7 powertech? 8.1 l diesel engines — base engine 032001 pn=467 continued on next page diagnostic specifications 06 210 8 dpsg,ouo1004,290 –19–23jul98–2/8 turbo boost pressures (john deere agricultural equipment) machine model engine model injection pump rated power full load turbo boost pressure at full load part # at full load rated speed rated speed rated speed rpm kpa (bar) (psi) kw (hp) 9650cts combine rg6081hh010 re503345 210 (281) 2200 172—211 kpa (1.72—2.11 bar) (25—31 psi) re61658 210 (281) 2200 136—167 kpa (1.36—1.67 bar) (20—24 psi) 9650ctse rg6081hh011 n/aa 242 (324) 2200 207—254 kpa (2.07—2.54 bar) (30—37 combine psi) zweibrucken, germany 2056 combine rg6081hz003 re62646 169 (226) 2200 123—151 kpa (1.23—1.51 bar) (17—22 psi) 2256 combine rg6081hz007 re501996 174 (234) 2200 128—158 kpa (1.28—1.58 bar) (18—23 psi) 2258/2058 rg6081hz005 re67359 188 (252) 2200 135—165 kpa (1.35—1.65 bar) (19—24 combine psi) 2264/2064 rg6081hz002 re62647 201 (270) 2200 149—183 kpa (1.49—1.83 bar) (21—27 combine psi) 2266/2066 rg6081hz001 re67358 212 (284) 2200 162—198 kpa (1.62—1.98 bar) (23—29 combine psi) re62686 224 (300) 2200 176—216 kpa (1.76—2.16 bar) (25—32 psi) re61658 207 (278) 2200 157—193 kpa (1.57—1.93 bar) (22—28 psi) re57373 207 (278) 2200 157—193 kpa (1.57—1.93 bar) (22—28 psi) 2268 combine rg6081hz006 re501867 233 (312) 2200 192—235 kpa (1.92—2.35 bar) (28—24 psi) 6650 self-propelled rg6081hz004 re61658 223 (299) 2100 171—209 kpa (1.71—2.09 bar) (24—31 forage harvester psi) horizontina, brazil 1185a combine rg6081acq01 re66243 168 (225) 2200 153—188 kpa (1.53—1.88 bar) (22—27 psi) an/a = not available at time of publication continued on next page ctm86 (20mar01) 06-210-8 powertech? 8.1 l diesel engines — base engine 032001 pn=468 diagnostic specifications 06 210 9 dpsg,ouo1004,290 –19–23jul98–3/8 turbo boost pressures (john deere agricultural equipment) continued machine model engine model injection pump rated power full load turbo boost pressure at full load part # at full load rated speed rated speed rated speed rpm kpa (bar) (psi) kw (hp) waterloo 7710 tractors rg6081trw01, n/aa 120 (161) 2100 100—124 kpa (1.00—1.24 bar) (14—18 03, 05, 07, 09 psi) 7810 tractors rg6081trw02, n/aa 135 (181) 2100 121—149 kpa (1.21—1.49 bar) (17—22 04, 06, 08, 10 psi) 8100/8100t rg6081hrw06, 10 re67771 141 (189) 2200 110—136 kpa (1.10—1.36 bar) (16—20 tractor psi) 8110/8110t rg6081hrw11, 12 re501859 152 (203) 2200 117—144 kpa (1.17—1.44 bar) (17—21 tractor psi) 8200/8200t rg6081hrw02, 07 re62645 159 (213) 2200 121—149 kpa (1.21—1.49 bar) (17—22 tractor psi) 8210/8210t rg6081hrw13, re501859 168 (226) 2200 133—163 kpa (1.33—1.63 bar) (19—24 tractor hrw14 psi) 8300/8300t rg6081hrw08, 09 re62645 176 (236) 2200 135—166 kpa (1.35—1.66 bar) (19—24 tractor psi) 8310/8310t rg6081hrw15, 16 re501859 190 (255) 2200 159—195 kpa (1.59—1.95 bar) (23—28 tractor psi) 8400/8400t rg6081hrw01, re61658 195 (261) 2200 140—172 kpa (1.40—1.72 bar) (20—25 tractor 03, 04 psi) 8410/8410t rg6081hrw17, 18 re501676 212 (284) 2200 156—191 kpa (1.56—1.91 bar) (23—28 tractor psi) 9100 tractor rg6081hrw05 re61658 191 (256) 2100 144—176 kpa (1.44—1.76 bar) (20—26 psi) an/a = not available at time of publication continued on next page ctm86 (20mar01) 06-210-9 powertech? 8.1 l diesel engines — base engine 032001 pn=469 diagnostic specifications 06 210 10 dpsg,ouo1004,290 –19–23jul98–4/8 turbo boost pressures (john deere construction equipment) machine model engine model injection rated power full load turbo boost pressure at full load pump part # at full load rated speed rated speed rated speed rpm kpa (bar) (psi) kw (hp) davenport 740g/748g skidder rg6081tdw01 re65102 128 (172) 2200 131—161 kpa (1.31—1.61 bar) (19—24 psi) 770ch/772ch rg6081hdw01 re68148 162 (217) 2000 154—190 kpa (1.54—1.90 bar) (22—28 motor grader psi) 770 c motor rg6081hdw01 re68148 162 (217) 2000 154—190 kpa (1.54—1.90 bar) (22—28 grader psi) rg6081hdw03 re66421 122 (163) 2000 114—140 kpa (1.14—1.40 bar) (16—21 psi) 644g loader rg6081hdw04 re66248 134 (179) 2200 113—139 kpa (1.13—1.39 bar) (16—20 psi) rg6081adw01 re64251 125 (167) 2100 111—137 kpa (1.11—1.37 bar) (16—20 psi) 644h loader rg6081hdw05 re62645 166 (223) 1800 130—160 kpa (1.30—1.60 bar) (18—24 psi) re62645 178 (238) 2200 160—196 kpa (1.60—1.96 bar) (23—29 psi) 644h/mh loader rg6081hdw06 re62645 191 (257) 1800 141—173 kpa (1.41—1.73 bar) (20—25 psi) re62645 178 (238) 2200 160—196 kpa (1.60—1.96 bar) (23—29 psi) lx150 loader 6081hdw70 re62645 166 (223) 1800 130—160 kpa (1.30—1.60 bar) (18—24 psi) re62645 150 (201) 2200 150—184 kpa (1.50—1.84 bar) (21—27 psi) dubuque 762b scraper rg6081at001 re66245 139 (187) 2100 138—170 kpa (1.38—1.70 bar) (20—25 psi) 850c crawler rg6081at002 re67448 132 (177) 2100 149—183 kpa (1.49—1.83 bar) (21—27 psi) 330lc/370 rg6081ht001 re71286 184 (247) 2000 162—198 kpa (1.62—1.98 bar) (23—29 excavator psi) timberjack 530b/535log rg6081atj01 n/aa 187 (251) 2200 n/aa loader 660d skidder rg6081atj02 n/aa 149 (200) 2200 n/aa an/a = not available at time of publication ctm86 (20mar01) 06-210-10 powertech? 8.1 l diesel engines — base engine 032001 pn=470 continued on next page diagnostic specifications 06 210 11 dpsg,ouo1004,290 –19–23jul98–5/8 turbo boost pressures (john deere oem/outside equipment manufacturers) engine number option code injection rated power at full load rated turbo boost pressure at full load pump part full load rated speed rated speed no. speed rpm kpa (bar) (psi) kw (hp) rg6081af001 1601, 1602 re502438 149 (200) 2200 137—169 kpa (1.37—1.69 bar) (20—25 psi) 1603 re66449 157 (211) 1500 142—174 kpa (1.42—1.74 bar) (20—25 psi) 1604, 1605 re66456 157 (211) 1500 142—174 kpa (1.42—1.74 bar) (20—25 psi) 1606 re503430 149 (200) 2200 137—169 kpa (1.37—1.69 bar) (20—25 psi) 1607 re66450 187 (251) 1500 179—219 kpa (1.79—2.19 bar) (26—32 psi) 1608, 1609 re66457 187 (251) 1500 179—219 kpa (1.79—2.19 bar) (26—32 psi) 1610 re62642 187 (251) 2200 171—209 kpa (1.71—2.09 bar) (24—30 psi) 1611 re66243 168 (227) 2200 171—209 kpa (1.71—2.09 bar) (24—30 psi) 1612, 1676 re62644 187 (251) 1800 174—214 kpa (1.74—2.14 bar) (25—31 psi) 1613 re501785 205 (275) 2200 186—228 kpa (1.86—2.28 bar) (27—33 psi) 1615 re501785, 205 (275) 2200 186—228 kpa (1.86—2.28 bar) (27—33 re62648 psi) 1617 re66244 168 (227) 2200 171—209 kpa (1.71—2.09 bar) (24—30 psi) 1618 re63766 187 (251) 2200 171—209 kpa (1.71—2.09 bar) (24—30 psi) 1619 re63767 187 (251) 2200 174—214 kpa (1.74—2.14 bar) (25—31 psi) 1620 re501786, 205 (275) 2200 190—233 kpa (1.90—2.33 bar) (27—33 re63768 psi) 1621 re503345, intermittent: 205 2200 intermittent: 190—234 kpa (1.90—2.34 re507686, (275) bar) (27—34 psi) re61658 continuous: 174 continuous: n/aa (233) 1622 re64162 224 (300) 1800 202—248 kpa (2.02—2.48 bar) (29—36 psi) 1623, 1624 re64214 224 (300) 1800 202—248 kpa (2.02—2.48 bar) (29—36 psi) an/a = not available at time of publication ctm86 (20mar01) 06-210-11 powertech? 8.1 l diesel engines — base engine 032001 pn=471 continued on next page diagnostic specifications 06 210 12 dpsg,ouo1004,290 –19–23jul98–6/8 turbo boost pressures (john deere oem/outside equipment manufacturers) engine number option code injection rated power at full load rated turbo boost pressure at full load pump part full load rated speed rated speed no. speed rpm kpa (bar) (psi) kw (hp) 1633, 1635, re503348, intermittent: 2200 intermittent: 190—234 kpa (1.90—2.34 1642, 1651, re507696, 205 (275) bar) (27—34 psi) 1652, 1653, re66463 continuous: continuous: n/aa 1654, 1655, 174 (233) 1656, 1658, 1659, 1662, 1668, 1669, 1670, 1671, 1672 1640 re62642, 187 (251) 2200 171—209 kpa (1.71—2.09 bar) (24—30 re 62646 psi) 1616, 1625, re503346, intermittent: 2200 intermittent: 171—209 kpa (1.71—2.09 1632, 1634, re507695, 187 (251) bar) (24—30 psi) 1641, 1643, re62643 continuous: continuous: n/aa 1644, 1645, 159 (213) 1646, 1647, 1648, 1649, 1650, 1661, 1663, 1664, 1665, 1666, 1667 1657 re66463 intermittent: 2200 intermittent: 190—234 kpa (1.90—2.34 205 (275) bar) (27—34 psi) continuous: continuous: n/aa 174 (233) 1660 re503175, intermittent: intermittent: 171—209 kpa (1.71—2.09 re503356, 187 (251) bar) (24—30 psi) re507697 continuous: continuous: 142—174 kpa (1.42—1.74 159 (213) bar) (20—25 psi) 1673, 1674 re506419 168 (227) 2200 171—209 kpa (1.71—2.09 bar) (24—30 psi) 1681 re502806 224 (300) 2350, 3100 226—277 kpa (2.26—2.77 bar) (33—40 psi) 216 (290) 1760 n/aa 179 (240) 1470 n/aa 1682, 1683 re503822 246 (330) 1800 249—305 kpa (2.49—3.05 bar) (36—44 psi) 1684, 1687 re503823 246 (330) 1800 249—305 kpa (2.49—3.05 bar) (36—44 psi) 1685, 1686 re505672 225 (302) 1500 n/aa 1688 re506543 205(275) 2200 190—234 kpa (1.90—2.34 bar) (27—34 psi) rg6081hf001 1601, 1602 re62686 224 (300) 2200 176—216 kpa (1.76—2.16 bar) (25—31 psi) an/a = not available at time of publication ctm86 (20mar01) 06-210-12 powertech? 8.1 l diesel engines — base engine 032001 pn=472 continued on next page diagnostic specifications 06 210 13 dpsg,ouo1004,290 –19–23jul98–7/8 turbo boost pressures (john deere oem/outside equipment manufacturers) engine number option code injection rated power at full load rated turbo boost pressure at full load pump part full load rated speed rated speed no. speed rpm kpa (bar) (psi) kw (hp) 1603, 1604 re62687 240 (322) 1800 209—257 kpa (2.09—2.57 bar) (30—38 psi) 1605 re63769 224 (300) 2200 176—216 kpa (1.76—2.16 bar) (25—31 psi) 1606 re63770 240 (322) 1800 209—257 kpa (2.09—2.57 bar) (30—38 psi) 1621, 1633, re503345, intermittent: 2200 intermittent: 176—216 kpa (1.76—2.16 1640, 1641, re507686, 224 (300) bar) (25—31 psi) 1642, 1643, re61658 continuous: continuous: 171—209 kpa (1.71—2.09 1644, 1645, 190 (255) bar) (24—30 psi) 1646, 1647, 1648, 1688, 1689, 1690, 1691, 1692, 1693 1622, 1623 re66458 200 (268) 1500 188—230 kpa (1.88—2.30 bar) (27—33 psi) 1624 re66451 200 (268) 1500 188—230 kpa (1.88—2.30 bar) (27—33 psi) 1639 re503345, intermittent: 2200 intermittent: 176—216 kpa (1.76—2.16 re61658 224 (300) bar) (25—31 psi) continuous: continuous: 171—209 kpa (1.71—2.09 190(255) bar) (24—30 psi) 1661, 1662, re503812 268 (360) 1500 n/aa 1684, 1686 1663 re503813 268 (360) 1500 n/aa 1680 re501861 224 (300) 2350 n/aa 224 (300) 2100 214—263 kpa (2.14—2.63 bar) (31—38 psi) 216 (290) 1760 n/aa 179 (240) 1470 n/aa 1681, 1682, re505670 308 (413) 1800 258—316 kpa (2.58—3.16 bar) (37—46 1685, 1687 psi) 1683 re505475 308 (413) 1800 258—316 kpa (2.58—3.16 bar) (37—46 psi) rg6081tf001 1601, 1602 re66241 149 (200) 2200 137—168 kpa (1.37—1.68 bar) (20—24 psi) 1603, 1604 re62837 157 (211) 1800 207—253 kpa (2.07—2.53 bar) (30—37 psi) 1605 re66242 149 (200) 2200 157—193 kpa (1.57—1.93 bar) (22—28 psi) 1606 re63750 157 (211) 1800 207—253 kpa (2.07—2.53 bar) (30—37 psi) an/a = not available at time of publication ctm86 (20mar01) 06-210-13 powertech? 8.1 l diesel engines — base engine 032001 pn=473 continued on next page diagnostic specifications 06 210 14 dpsg,ouo1004,290 –19–23jul98–8/8 turbo boost pressures (john deere oem/outside equipment manufacturers) engine number option code injection rated power at full load rated turbo boost pressure at full load pump part full load rated speed rated speed no. speed rpm kpa (bar) (psi) kw (hp) 1608, 1609 re66459 131 (176) 1500 157—193 kpa (1.57—1.93 bar) (22—28 psi) 1610 re66448 131 (176) 1500 157—193 kpa (1.57—1.93 bar) (22—28 psi) 1611, 1612 re501016 128(172) 2200 127—156 kpa (1.27—1.56 bar) (18—23 psi) 1613 re501198 128(172) 2200 127—156 kpa (1.27—1.56 bar) (18—23 psi) 1614, 1615 re505268 185(248) 1800 183—225 kpa (1.83—2.25 bar) (26—33 psi) 1616 re505269 185(248) 1800 183—225 kpa (1.83—2.25 bar) (26—33 psi) rg6081afm01 1601, 1602 n/aa 280 (375) 2400 200—250 kpa (2.0—2.5 bar) (29—36 psi) n/aa 246 (330) 2300 160—195 kpa (1.6—1.95 bar) (23—28 psi) n/aa 224 (300) 2200 125—175 kpa (1.25—1.75 bar) (18—25 psi) n/aa 175 (235) 2100 95—115 kpa (0.95—1.15 bar) (13—16 psi) 1603, 1604 n/aa 168 (225) 1800 128—157 kpa (1.28—1.57 kpa) (18.6— 23.0 psi) 1605, 1606 n/aa 139 (186) 1500 117—144 kpa (1.17—1.44 kpa) (17—21 psi) rg6081hf070 16ga, 16gb, n/aa prime: 220 (295) 1800 prime: 183—225 kpa (1.83—2.25 bar) 16gc, 16gd standby: 259 (26.5—32 psi) (347) standby: 216—264 kpa (2.16—2.64 bar) (31—38 psi) 16ja, 16jb, n/aa prime: 263 (353) 1800 prime: 217—266 kpa (2.17—2.66 bar) 16jc, 16jd standby: 308 (31—38 psi) (413) standby: 243—297 kpa (2.43—2.97 bar) (35—42 psi) 166a, 166b, n/aa intermittent: 242 2200 intermittent: 194—238 kpa (1.94—2.38 166c, 166d, (325) bar) (28—34 psi) 166e, 166f, continuous: 224 continuous: 181—221 kpa (1.81—2.21 166g, 166h (300) bar) (26—32 psi) 166l, 166m, n/aa intermittent: 224 2200 intermittent: 181—221 kpa (1.81—2.21 166n, 166p, (300) bar) (26—32 psi) 166r, 166s, continuous: 205 continuous: 167—204 kpa (1.67—2.04 166t, 166u (275) bar) (24—29 psi) an/a = not available at time of publication ctm86 (20mar01) 06-210-14 powertech? 8.1 l diesel engines — base engine 032001 pn=474 diagnostic specifications rg,rg34710,1064 –19–08jun99–1/1 06 effects of altitude&temperature on engine performance rg9094 –un–27mar98 turbocharged engines altitude, fuel temperature, air temperature,&humidity may affect engine performance. as a general rule, atmospheric changes will usually cause a decrease in engine power by the percentages shown in chart below. atmospheric change % power decrease fuel temperature rise of 1°c (1.8°f) above 40° c (104°f)   . 0.29 air temperature rise of 5.5°c (10°f) above 25°c (77°f)   . 0.50 naturally aspirated engines: altitude rise of 300 m (1000 ft) above 180 m (600 ft)    3.00 turbocharged engines: altitude rise of 300 m (1000 ft) above 180 m (600 ft)    0.50 relative humidity rise of 10% above 0%    0.07 210 15 ctm86 (20mar01) 06-210-15 powertech? 8.1 l diesel engines — base engine 032001 pn=475 diagnostic specifications 06 210 16 ctm86 (20mar01) 06-210-16 powertech? 8.1 l diesel engines — base engine 032001 pn=476 index page page a install thrust washer&timing gear cover      02-050-20 actuator, wastegate journals&bushings, measure  02-050-12 adjust      04-150-30 lobe lift, measure   02-050-13 test      04-150-29 remove camshaft   02-050-8 aftercooler specifications   06-200-22 assemble&install thrust washers, measure   02-050-11 horizontally-mounted   02-080-25 check disassemble horizontally-mounted   02-080-19 engine crankcase pressure (blow-by)   04-150-15 inspect&repair   02-080-20 engine cranking speed   04-150-13 install vertically-mounted (6081a)   02-080-22 engine oil pressure   04-150-14 remove horizontally-mounted  02-080-19 exhaust air leaks (turbocharged remove vertically-mounted   02-080-18 engines)    .04-150-28 air intake&exhaust system exhaust restrictions  04-150-26 specifications   06-200-29 head gasket failures   04-150-20 air intake system intake restrictions   04-150-26 operation      03-120-14 turbocharger oil seal leak  04-150-16 air intake system, check  02-010-16 connecting rods alternator bearings, inspect&measure  02-030-27 install      02-100-1 disassemble   02-030-11 remove      02-100-1 general information  02-030-2 altitude, effects on engine performance   06-210-15 install      02-030-38 assembly, rocker arm torque-turn cap screws  02-030-43 inspect (s.n. 200,000- )   02-021-16 coolant auxiliary drive, remove&install   02-050-3 additional information   01-002-11 diesel engine   01-002-10 disposal      01-002-16 replenishing supplemental additives  01-002-13 b testing      01-002-12 warm temperature climates   01-002-14 belt tensioner, inspect   02-070-10 coolant heater, service  02-070-21 bio-diesel fuel    .01-002-2 coolant pump indx block, cylinder install      02-070-16 1 clean&inspect top deck coolant temperature switch, remove and (s.n -199,999)  02-020-30 install      02-070-20 (s.n. 200,000- )  02-021-32 cooling orifices, piston disassemble   02-030-30 remove&clean   02-030-30 blow-by cooling system check      04-150-15 check&service   02-010-17 diagnostics coolant in oil/oil in coolant   04-150-10 c engine coolant temperature above normal      04-150-9 camshaft engine coolant temperature below bushings, service (jdg602)   02-050-15 normal    .04-150-10 bushings, service (jdg606)   02-050-17 flush&service   01-002-15 complete final assembly   02-050-21 pressure test  04-150-18 end play&backlash, check  02-050-1 specifications   06-200-27 followers, inspect&measure   02-050-11 theory of operation  03-120-10 gears, install  02-050-14 crankcase ventilation system, check   02-010-16 gears, remove   02-050-10 crankshaft inspect      02-050-12 complete final assembly   02-040-50 install camshaft  02-050-19 end play, check   02-040-8 ctm86 (20mar01) index-1 powertech? 8.1 l diesel engines — base engine 032001 pn=1 index page page failure analysis  02-040-1 install (s.n. 200,000- )   02-021-35 front oil seal&wear sleeve, measure thickness (s.n -199,999)   02-020-21 remove      02-040-10 measure thickness (s.n. 200,000- )   02-021-25 front oil seal, install   02-040-46 preliminary checks (s.n -199,999)   02-020-14 front sleeve, install  02-040-45 preliminary checks (s.n. 200,000- )   02-021-18 gear, replace   02-040-33 remove (s.n. 200,000-)   02-021-9 grinding guidelines   02-040-29 specifications   06-200-7 grinding specifications   02-040-31 torque-to-yield cap screws inspect      02-040-24 (s.n -199,999)  02-020-35 install      02-040-35 (s.n. 200,000- )  02-021-37 journals&bearings, measure   02-040-25 cylinder head gasket main bearing cap line bore diagnosing failures (s.n. 200,000- )   02-021-11 specifications  02-040-27 diagnostic chart (s.n. 200,000- )   02-021-13 rear oil seal&sleeve, general inspection&repair (s.n -199,999)   02-020-9 information   .02-040-2 inspection&repair (s.n. 200,000- )   02-021-14 rear oil seal&sleeve, handling   02-040-5 cylinder liners rear oil seal&sleeve, install  02-040-6 inspect      02-030-16 rear oil seal&sleeve, remove   02-040-3 install      02-030-37 rear oil seal&wear sleeve, install   02-040-42 manufacturing date code  02-030-18 rear oil seal housing runout   02-040-40 measure flange   02-030-26 rear oil seal housing, install   02-040-38 measure standout   02-030-7 remove      02-040-23 thrust bearing specifications  02-040-28 measure standout (s.n -199,999)   02-020-31 crankshaft gear-to-oil pump drive gear measure standout (s.n. 200,000- )   02-021-33 check backlash  02-060-12 o-rings&packing, install  02-030-36 cylinder block preliminary checks   02-030-1 clean&inspect top deck recheck standout   02-030-34 (s.n -199,999)  02-020-30 remove      02-030-8 (s.n. 200,000- )  02-021-32 disassemble   02-030-30 inspect&clean   02-030-31 measure      02-030-33 d cylinder block, liners, pistons&rods, indx 2 specifications   06-200-14 damper, vibration, remove   02-050-2 cylinder head dealer fabricated tool check flatness (s.n -199,999)   02-020-20 cylinder liner holding fixture   05-190-1 check flatness (s.n. 200,000- )   02-021-24 diagnostics clean (s.n. 200,000- )   02-021-23 coolant system malfunctions complete assembly of manifold side coolant in oil/oil in coolant   04-150-10 (s.n. -199,999)   02-020-39 engine coolant temperature above (s.n. 200,000- )  02-021-41 complete assembly of pump side normal      04-150-9 (s.n. -199,999)   02-020-38 engine coolant temperature below (s.n. 200,000- )  02-021-40 normal    .04-150-10 diagnosing gasket failures lubrication system malfunctions (s.n. 200,000- )  02-021-11 engine oil pressure high   04-150-8 gasket diagnostic chart engine oil pressure low   04-150-6 (s.n. 200,000- )  02-021-13 execessive oil consumption  04-150-2 gasket inspection&repair diesel engine oil  01-002-6 (s.n -199,999)  02-020-9 diesel fuel      01-002-1 (s.n. 200,000- )  02-021-14 drive, fan inspect (s.n -199,999)   02-020-19 replace bearings (adjustable)  02-070-1 inspect (s.n. 200,000- )   02-021-23 replace bearings (fixed)   02-070-4 ctm86 (20mar01) index-2 powertech? 8.1 l diesel engines — base engine 032001 pn=2 index page page e exhaust system check      02-010-17 electrical system operation      03-120-14 check      02-010-19 specifications   06-200-29 specifications   06-200-30 engine assembly sequence   02-010-11 f break-in guidelines   02-010-13 break-in, perform   02-010-14 fan assembly break-in, perform (s.n. -199,999)   02-020-40 inspect&install   02-070-12 break-in, perform (s.n. 200,000- )   02-021-42 fan drive assembly check for excessive tightness  02-030-44 install      02-070-5 clean      02-010-4 replace bearings (adjustable)  02-070-1 cooling system   03-120-10 replace bearings (fixed)   02-070-4 disassembly sequence   02-010-8 filter general operation   03-120-3 oil, changing top-load   02-060-4 lifting procedure   02-010-3 fitler lubrication system   03-120-5 oil, top-load assembly  02-060-3 model designation  01-001-1 flywheel mount on repair stand  02-010-6 check face flatness  02-040-15 option code label   01-001-3 inspect&measure   02-040-14 overhaul guidelines   02-010-1 install      02-040-49 repair stand    .02-010-1 remove      02-040-16 repair stand adapters, install   02-010-2 ring gear, replace   02-040-17 sectional view s.n. ( -200,000)   03-120-1 flywheel housing sectional view s.n. (200,000- )   03-120-2 check face runout  02-040-14 serial number plate  01-001-2 install (sae 1)  02-040-50 specifications   06-200-1, 06-200-3 install (sae 2&3)  02-040-48 theory of operation  03-120-3 remove (sae 1)  02-040-16 tune-up recommendations   02-010-21 remove (sae 2&3)  02-040-17 engine application chart front oil seal&wear sleeve, crankshaft indx john deere agricultural equipment  01-001-4 remove      02-040-10 3 engine compression pressure fuel specifications   06-210-1 bio-diesel      01-002-2 test      04-150-11 diesel      01-002-1 engine crankcase pressure (blow-by) check      04-150-15 engine cranking speed g check      04-150-13 engine oil grease break-in      01-002-5 extreme pressure&multipurpose   01-002-9 diesel      01-002-6 engine oil pressure check      04-150-14 engine operation h general engine information   03-120-3 exhaust air leaks (turbocharged engines) head gasket check      04-150-28 construction&operation   03-120-12 exhaust manifold diagnosing failures (s.n. 200,000- )   02-021-11 remove, inspect&install   02-080-15 diagnostic chart (s.n. 200,000- )   02-021-13 exhaust restrictions inspection&repair (s.n -199,999)   02-020-9 check      04-150-26 inspection&repair (s.n. 200,000- )   02-021-14 ctm86 (20mar01) index-3 powertech? 8.1 l diesel engines — base engine 032001 pn=3 index page page head gasket failures measure standout (s.n. 200,000- )   02-021-33 check      04-150-20 o-rings&packings, install   02-030-36 head, cylinder shims, install  02-030-35 check flatness (s.n -199,999)   02-020-20 lubricant check flatness (s.n. 200,000- )   02-021-24 mixing      01-002-7 diagnosing gasket failures lubrication (s.n. 200,000- )  02-021-11 turbocharger   03-120-16 inspect&clean nozzle bore lubrication system (s.n -199,999)  02-020-27 diagnosing malfunctions   02-060-1 (s.n. 200,000- )  02-021-31 diagnostics inspect&clean (s.n -199,999)   02-020-19 engine oil pressure high   04-150-8 inspect&clean (s.n. 200,000- )   02-021-23 engine oil pressure low   04-150-6 inspection&repair (s.n. 200,000- )   02-021-14 excessive oil consumption   04-150-2 install (s.n -199,999)   02-020-33 specifications   06-200-24 install (s.n. 200,000- )   02-021-35 theory of operation  03-120-5 measure thickness (s.n. 200,000- )   02-021-25 lubricity of diesel fuel  01-002-4 preliminary checks (s.n. 200,000- )   02-021-18 remove (s.n -199,999)   02-020-6 remove (s.n. 200,000-)   02-021-9 m heater, coolant servicing     02-070-21 main bearings, crankshaft hose, ventilator outlet check oil clearance  02-040-22 inspect&clean (s.n -199,999)    02-020-29, install      02-040-35 02-020-37 remove caps   02-040-20 inspect&clean (s.n. 200,000- )   02-021-39 manifold, water install      02-070-20 remove      02-070-18 i metric torque values   06-200-6 mixing lubricants  01-002-7 inch torque values   06-200-5 model designation intake air leaks engine      01-001-1 test      04-150-27 intake manifold indx 4 inspect&repair (6081a)   02-080-21 o install (6081a)  02-080-22 remove, inspect&install   02-080-17 oil consumption, excessive   04-150-2 intake manifold pressure oil cooler measure      04-150-24 inspect      02-060-8 intake manifold pressure (turbo boost) install      02-060-8 specifications   06-210-7 remove      02-060-8 intake restrictions oil cooler bypass valve check      04-150-26 remove, inspect,&install   02-060-10 oil cooler cross-over tube adapter, remove and install      02-060-18 l oil filter changing top-load  02-060-4 liners, cylinder top-load assembly   02-060-3 clean      02-030-10 oil filter base deglaze      02-030-9 assembly      02-060-2 holding fixture  05-190-1 remove&install   02-060-5 manufacturing date code  02-030-18 oil filter bypass valve measure standout (s.n -199,999)   02-020-31 remove, inspect,&install   02-060-10 ctm86 (20mar01) index-4 powertech? 8.1 l diesel engines — base engine 032001 pn=4 index page page oil pan check drive shaft end play   02-060-14 install      02-060-20 check pumping gear backlash   02-060-15 remove      02-060-11 check shaft side movement   02-060-14 oil pressure inspect&clean   02-060-13 check      04-150-14 inspect drive gear   02-060-15 oil pressure high   04-150-8 install      02-060-16 oil pressure low   04-150-6 remove      02-060-12 oil pressure regulating valve pump, water remove, inspect,&install   02-060-10 inspect      02-070-13 oil pressure regulating valve housing remove      02-070-14 assembly      02-060-2 push rods remove&install   02-060-5 clean&inspect (s.n -199,999)   02-020-29 oil pump clean&inspect (s.n. 200,000- )  02-021-32 access (8000 series tractors)   02-060-11 adjust set screw   02-060-16 check drive gear backlash   02-060-12 check drive shaft end play   02-060-14 r check pumping gear backlash   02-060-15 check shaft side movement   02-060-14 radiator cap drive gear, replace   02-040-32 pressure test  04-150-18 inspect&clean   02-060-13 rear oil seal&sleeve, crankshaft inspect drive gear   02-060-15 general information  02-040-2 install      02-060-16 handling precautions   02-040-5 outlet tube, remove&install   02-060-18 install   02-040-6, 02-040-42 pickup tube, remove&install   02-060-19 remove      02-040-3 remove      02-060-12 rear oil seal housing oil sump, install (8000 series tractors)   02-060-22 check runout   02-040-40 remove&install (with engine installed on 8000 series tractor)   02-040-18 remove (with engine removed)  02-040-19 p rocker arm assembly assemble (s.n -199,999)   02-020-12 indx 5 pilot bearing, check concentricity   02-040-15 assemble (s.n. 200,000- )   02-021-17 piston disassemble (s.n -199,999)   02-020-11 clean      02-030-12 disassemble (s.n. 200,000- )   02-021-17 disassemble   02-030-11 inspect (s.n -199,999)   02-020-11 inspect      02-030-13 inspect (s.n. 200,000- )   02-021-16 inspect pin&bore   02-030-15 install (s.n -199,999)   02-020-36 inspect pins&bushings  02-030-23 install (s.n. 200,000- )   02-021-39 pin bushing, install   02-030-29 rod, connecting preliminary checks   02-030-1 bearings, inspect&measure  02-030-27 remove      02-030-3 inspect rod&cap   02-030-21 remove pin bushing&clean bore  02-030-25 install      02-030-38 ring groove, check wear  02-030-14 piston cooling orifices install      02-030-34 remove&clean   02-030-30, 02-040-34 s piston-to-liner clearance measure      02-030-19 sealant application guidelines   02-010-9 pump, coolant shaft, rocker arm assembly install      02-070-16 assemble (s.n. 200,000- )   02-021-17 pump, oil disassemble (s.n. 200,000- )   02-021-17 adjust set screw   02-060-16 inspect (s.n -199,999)   02-020-11 ctm86 (20mar01) index-5 powertech? 8.1 l diesel engines — base engine 032001 pn=5 index page page specifications remove (with engine removed)   02-040-13, air intake&exhaust system   06-200-29 02-050-2 camshaft&timing gear train   06-200-22 timing gear train specifications   06-200-22 cooling system   06-200-27 tools crankshaft, main bearings&engine diagnostic&procedure   05-180-1 flywheel      06-200-18 top-load oil filter cylinder block, liners, pistons&assembly      02-060-3 rods     06-200-14 changing      02-060-4 cylinder head&valves   06-200-7 torque values electrical system  06-200-30 inch     06-200-5 engine compression pressure   06-210-1 metric      06-200-6 engine, general  06-200-1, 06-200-3 tune-up recommendations   02-010-21 intake manifold pressure (turbo boost)  06-210-7 turbo boost lubrication system   06-200-24 measure      04-150-24 thermostat      06-210-2 specifications   0廊坊约翰迪尔6081发动机凸轮轴塞的价格,珠海约翰迪尔3029柴油发动机配件批发商,许昌JohnDeere曲轴RE506195批发商,白银强鹿活塞销R517073批发价,莆田强鹿6090柴油发动机节温器一级代理,三门峡JohnDeere气门锁夹R502371供应商,阿勒泰强鹿滤芯滤清器RE57394哪里买,阿拉善约翰迪尔装载机发动机缸体哪里买,庆阳约翰迪尔加大止推轴承瓦RE61253供应商,黑河约翰迪尔柴油机T20034凸轮轴下衬套供货商,西安JohnDeere加大止推轴承瓦RE504199厂家供应,连云港强鹿6090柴油发动机机油底壳垫片市场报价,牡丹江强鹿柴油机RE504914油泵信息,6-210-7 timing gear train  06-200-22 turbocharger turbo boost    .06-210-7 axial bearing end play  02-080-11 turbocharger wastegate actuator   06-210-1 disconnect oil inlet line   02-010-5 wastegate actuator  06-210-1 extending life   02-080-1 starter motor failure analysis  02-080-4 remove&install   02-100-2 install      02-080-13 supplemental coolant additives lubrication    .03-120-16 replenishing   01-002-13 operation      03-120-14 prelube      02-080-12 remove      02-080-3 repair     02-080-12 t seven-step inspection  02-080-6 wastegate operation   03-120-15 turbocharger oil seal leak temperature, effects on engine check      04-150-16 performance   06-210-15 turbocharger wastegate actuator test specifications   06-210-1 cooling system   04-150-18 turbocharger, wastegate actuator engine compression pressure   04-150-11 indx 6 adjust      04-150-30 intake air leaks   04-150-27 test      04-150-29 radiator cap   04-150-18 thermostat opening temperature   04-150-17 turbocharger wastegate actuator   04-150-29 wastgate actuator  04-150-29 v thermostat inspect      04-150-17 valve assembly specifications   06-210-2 assemble (s.n -199,999)   02-020-32 test opening temperature   04-150-17 assemble (s.n. 200,000- )   02-021-34 thermostats valve clearance install      02-070-19 adjust (serial numbers 200,000-)   02-021-4 remove&test  02-070-17 check&adjust (s.n -199,999)   02-020-1 thrust bearings, crankshaft check (serial numbers 200,000-)   02-021-1 inspect      02-040-34 valve guides timing gear cover clean (s.n -199,999)   02-020-22 install      02-040-44 clean (s.n. 200,000- )   02-021-26 install (with engine removed)   02-050-20 knurl (s.n -199,999)   02-020-23 remove&install (with engine installed on 8000 knurl (s.n. 200,000- )  02-021-27 series tractor)  02-040-12 measure (s.n -199,999)   02-020-22 ctm86 (20mar01) index-6 powertech? 8.1 l diesel engines — base engine 032001 pn=6 index page page measure (s.n. 200,000- )   02-021-26 ventilation outlet hose valve lift, check (s.n -199,999)   02-020-5 inspect&clean (s.n -199,999)    02-020-29, valve lift, check (s.n. 200,000-)   02-021-8 02-020-37 valve recess, measure (s.n -199,999)   02-020-13 inspect&clean (s.n. 200,000- )   02-021-39 valve recess, measure (s.n. 200,000- )  02-021-17 ventilation system, crankcase, check   02-010-16 valve seat inserts vibration damper install (s.n -199,999)   02-020-27 inspect      02-040-7 install (s.n. 200,000- )   02-021-31 install      02-040-47 remove (s.n. 200,000- )   02-021-30 remove   02-040-9, 02-050-2 valve seats clean&inspect (s.n -199,999)   02-020-23 clean&inspect (s.n. 200,000- )  02-021-27 w grind (s.n -199,999)  02-020-25 grind (s.n. 200,000- )  02-021-29 wastegate actuator install inserts (s.n. 200,000- )  02-021-31 specifications   06-210-1 measure (s.n -199,999)   02-020-24 test      04-150-29 measure (s.n. 200,000- )   02-021-28 wastgate actuator remove inserts (s.n -199,999)  02-020-26 adjust      04-150-30 remove inserts (s.n. 200,000- )  02-021-30 water manifold valve spring install      02-070-20 caps&retainers, remove      02-070-18 inspect (s.n -199,999)  02-020-17 water pump inspect (s.n. 200,000- )  02-021-20 inspect      02-070-13 inspect&measure (s.n -199,999)   02-020-16 install      02-070-16 remove      02-070-14 inspect&measure (s.n. 200,000- )   02-021-20 water pump cover bypass tube seal, valve, engine replace      02-070-17 assemble (s.n. 200,000- )   02-021-34 clean (s.n -199,999)   02-020-17 clean (s.n. 200,000- )   02-021-21 valve, engine indx clearance, adjust (serial numbers 7 200,000-)     02-021-4 valve, engine clearance, check, (serial numbers 200,000-)     02-021-1 grind (s.n -199,999)  02-020-19 grind (s.n. 200,000- )  02-021-22 inspect (s.n -199,999)   02-020-18 inspect (s.n. 200,000- )   02-021-21 lift, check (s.n -199,999)   02-020-5 lift, check (s.n. 200,000-)   02-021-8 measure bore in cylinder (s.n -199,999)  02-020-26 (s.n. 200,000- )  02-021-30 measure (s.n. 200,000- )   02-021-21 preliminary checks (s.n -199,999)   02-020-14 preliminary checks (s.n. 200,000- )   02-021-18 recess, measure (s.n -199,999)   02-020-13 recess, measure (s.n. 200,000- )   02-021-17 remove (s.n -199,999)   02-020-15 remove (s.n. 200,000- )   02-021-19 ctm86 (20mar01) index-7 powertech? 8.1 l diesel engines — base engine 032001 pn=7 index indx 8 ctm86 (20mar01) index-8 powertech? 8.1 l diesel engines — base engine 032001 pn=8KEY PART NO. PART NAME QTY SERIAL NO. F F F REMARKS
1 .. HOLDER NA X X
2 T24210 O-RING 6 X X
3 R76358 O-RING 1 X X
4 14M7297 NUT 3 X M5
14M7272 NUT 3 X M6
5 12H296 WASHER 3 X 0.216"
12M7006 LOCK WASHER 3 X 0.236"
6 R67879 GASKET 1 X X
7 R53899 WASHER 1 X X
8 RE36151 CONTROL VALVE 1 X
AR77114 CONTROL VALVE 1 X
9 R53901 WASHER 1 X X
10 R63016 ADAPTER 1 X X
11 R67364 ELBOW FITTING 1 -087549 X X
RE502650 FITTING 1 087550- X XKEY PART NO. PART NAME QTY SERIAL NO. F F F REMARKS
1 RE65265 HAND PRIMER 1 X X (SUB FOR RE48048)
2 R54025 WASHER 1 X X
3 R26448 O-RING 2 X X
4 RE34128 ELBOW FITTING 1 X (A)
RE10258 ELBOW FITTING 1 X (B)
RE34128 ELBOW FITTING 2 X
5 R67879 GASKET 1 X X
6 RE46252 FUEL PUMP 1 X X (ROBERT BOSCH)
7 R93008 WASHER NA X
R53899 WASHER 1 X
8 R83489 FITTING NA X
R83490 FITTING 1 X
(A) INLET (B) OUTLET
ENTREE SORTIE
EINLASS AUSCLASSE
ENTRATA USCITA
ENTRADA SALIDA
INLOPP UTLOPPKEY PART NO. PART NAME QTY SERIAL NO. F F F REMARKS
1 R60914 SET SCREW 1 X
2 R53918 PACKING 1 X
3 T31556 NUT 1 X
4 R68715 PIN 1 X
5 AR89339 SEAL 1 X
6 AR89578 LEVER 1 X
7 24M7054 WASHER 1 X 6.400 X 12 X 1.600 MM
8 T24229 LOCK WASHER 2 X
9 R68716 NUT 1 X
10 R112128 LEVER 1 X (A)
11 19M8826 SCREW 2 X M6 X 16
12 R53976 SCREW 1 X (B)
13 24H1287 WASHER 1 X (B) 9/32" X 5/8" X 0.065"
14 R98677 LEVER 1 X (C)
15 R68438 RETAINER 1 X
16 R53955 O-RING 1 X
(A) THROTTLE (TWO HOLES AT TOP) (B) NOT INCLUDED (C) SHUT-OFF
MANETTE DES GAZ NON INCLUS ROBINET D’ARRET
DROSSELKLAPPE NICHT MIT ABSCHALTUNG
ACCELERATORE NON COMPRESO RUBINETTO D’ARRESTO
ACELERADOR NO FORMA PARTE GRIFO DECIERRE
GASREGLAGE INGAAR INTE AVSTAENGING
