首页 产品展示>英国Perkins珀金斯柴油发动机2306C原装进口零配件

英国Perkins珀金斯柴油发动机2306C原装进口零配件

珀金斯零配件 珀金斯发动机广泛应用于: ●发电机组(例如:威尔信发电机组) ●工程机械(例如:JCB小型挖掘机、英格索兰山猫小型挖掘机、福格勒摊铺机、美国威猛摊铺机、特雷克斯两头忙) ●叉车(林德、海斯特、永恒力、台励福) ●农业机械(例如:拖拉机、联合收割机) ●其它工业设备(例如:吉尼(GENIE)高空作业车、JLG高空作业车) 2000系列 技术已相当成2000系列升发动机是为应对当今发电行业的严苛要求而专门设计的,该系列发动机尤其适用于备用发电领域。具有优良的电力输出性能及燃油经济性,可靠耐用,燃油耗率低、噪音小、排放低。实现了最佳的动力匹配,可以提供适合各种用途和需求的发电系统。
产品咨询

详细描述

 EXHAUST VALVE
英国Perkins珀金斯柴油发动机2306C零配件
BuildList: FGBF4021
序号 零件名称 零件号 数量(一车付)
1             PRE-FUEL FILTER CH10930 1
2             Fuel Filter CH10931 1
3             Oil Filter CH10929 1
4             Air Filter  CH11217 1
5             ALT BELT CH11202 1
6             FAN BELT CH11186 1
7             SEAL - ROCKER BOX COVER CH11353 1
8             GASKET - CYLINDER HEAD KRP1529 1
9             THERMOSTAT CH11620 2
10         FRONT OIL SEAL CH11379 1
11         SEAL - REAR END OIL CH11304 1
12         PRE-FUEL FILTER CH10930 1
13         Fuel Filter CH10931 1
14         Oil Filter CH10929 1
15         ALT BELT CH11202 1
16         FAN BELT CH11186 1
17         Air Filter  CH11217 1
18         SEAL - ROCKER BOX COVER CH11353 1
19         GASKET - CYLINDER HEAD KRP1529 1
20         PISTON RING KIT KRP1569 6
21          EXHAUST VALVE CH11022 12
22         INTAKEVALVE CH11021 12
23         INJECTOR P/CH10948 6
24         THERMOSTAT CH11620 2
25         TOP GASKET KIT  KRP1546 1
26         BOTTOM GASKET KIT KRP1547 1
27         Fuel Filter CH10930 1
28         Pre-Fule Filter CH10931 1
29         Oil Filter CH10929 1
30         FAN BELT CH11186 1
31         ALTERNATOR BELT CH11202 1
32         Air Filter  CH11217 1
33         THERMOSTAT CH11620 2
34         VALVE SEAT INSERT CH10731 12
35         VALVE SEAT INSERT CH10732 12
36         SEAL - VALVE STEM CH11486 24
37         VALVE GUIDE CH10724 24
38         EXHAUST VALVE CH11022 12
39         INTAKE VALVE CH11021 12
40         VALVE COLLET CH10019 48
41         VALVE SPRING OUTER CH12798 24
42         VALVE SPRING INNER CH11489 24
43         SEAT CH10715 24
44         BIG END BEARING KIT KRP3027 1
45         PISTON KIT KRP1566 6
46         PISTON RING KIT KRP1569 6
47         CYLINDER LINER CH11180 6
48         BAND CH10673 6
49         SEAL - O RING CH10674 6
50         SEAL - O RING CH10677 6
51         SEAL - O RING CH11179 6
52         MAIN BEARING KIT KRP3116 1
53         THRUST WASHER KIT KRP3206 1
54         STARTER MOTOR CH12405 1
55         WATER PUMP KRP1553 1
56         ALTERNATOR CH11087 1
57         INJECTOR P/CH10948 6
58         TURBOCHARGER P/CH11218 1
59         GASKET - TURBOCHARGER CH11471 1
60         GASKET - CYLINDER HEAD KRP1529 1
61         SEAL - ROCKER BOX COVER CH11353 1
62         FRONT OIL SEAL CH11379 1
63         SEAL - REAR END OIL CH11304 1
64         SEAL - SUMP CH10887 1
65         LIFT PUMP KRP1679 1
66         OIL PUMP CH10860 1
67         AIR TEMPERATURE SENSOR KIT KRP1556 1
68         AIR PRESSURE SENSOR KIT KRP1558 1
69         OIL PRESSURE SENSOR KIT KRP1559 1
70         AIR PRESSURE SENSOR KIT KRP1560 1
71         SENSOR KRP1557 1
72         SPEED SENSOR KRP1551 1
73         SPEED SENSOR KRP1561 1
74         CRANKSHAFT ASSEMBLY CH11176 1
75         CAMSHAFT CH12778 1
76         GASKET KIT - TOP KRP1546 1
77         GASKET KIT - BOTTOM KRP1547 1
    英国Perkins珀金斯柴油发动机2306C-E14TAG3原装进口零配件
BuildList: FGDF4024
序号 零件名称 零件号 数量(一车付)
1             PRE-FUEL FILTER CH10930 1
2             Fuel Filter CH10931 1
3             Oil Filter CH10929 1
4             Air Filter  CH11217 1
5             ALT BELT CH11202 1
6             FAN BELT CH11186 1
7             SEAL - ROCKER BOX COVER CH11353 1
8             GASKET - CYLINDER HEAD KRP1529 1
9             THERMOSTAT CH11620 2
10         FRONT OIL SEAL CH11379 1
11         SEAL - REAR END OIL CH11304 1
12         PRE-FUEL FILTER CH10930 1
13         Fuel Filter CH10931 1
14         Oil Filter CH10929 1
15         ALT BELT CH11202 1
16         FAN BELT CH11186 1
17         Air Filter  CH11217 1
18         SEAL - ROCKER BOX COVER CH11353 1
19         GASKET - CYLINDER HEAD KRP1529 1
20         PISTON RING KIT KRP1569 6
21        CH11022 12
22         INTAKEVALVE CH11021 12
23         INJECTOR P/CH10948 6
24         THERMOSTAT CH11620 2
25         TOP GASKET KIT  KRP1546 1
26         BOTTOM GASKET KIT KRP1547 1
27         Fuel Filter CH10930 1
28         Pre-Fule Filter CH10931 1
29         Oil Filter CH10929 1
30         FAN BELT CH11186 1
31         ALTERNATOR BELT CH11202 1
32         Air Filter  CH11217 1
33         THERMOSTAT CH11620 2
34         VALVE SEAT INSERT CH10731 12
35         VALVE SEAT INSERT CH10732 12
36         SEAL - VALVE STEM CH11486 24
37         VALVE GUIDE CH10724 24
38         EXHAUST VALVE CH11022 12
39         INTAKE VALVE CH11021 12
40         VALVE COLLET CH10019 48
41         VALVE SPRING OUTER CH11487 24
42         VALVE SPRING INNER CH11489 24
43         SEAT CH10715 24
44         BIG END BEARING KIT KRP3012 1
45         PISTON KIT KRP1566 6
46         PISTON RING KIT KRP1569 6
47         CYLINDER LINER CH11180 6
48         BAND CH10673 6
49         SEAL - O RING CH10674 6
50         SEAL - O RING CH10677 6
51         SEAL - O RING CH11179 6
52         MAIN BEARING KIT KRP3116 1
53         THRUST WASHER KIT KRP3206 1
54         STARTER MOTOR CH12807 1
55         WATER PUMP KRP1553 1
56         ALTERNATOR CH11087 1
57         INJECTOR P/CH10948 6
58         TURBOCHARGER R/CH11218 1
59         GASKET - TURBOCHARGER CH11471 1
60         GASKET - CYLINDER HEAD KRP1529 1
61         SEAL - ROCKER BOX COVER CH11353 1
62         FRONT OIL SEAL CH11379 1
63         SEAL - REAR END OIL CH11304 1
64         SEAL - SUMP CH10887 1
65         LIFT PUMP KRP1679 1
66         OIL PUMP CH10860 1
67         AIR TEMPERATURE SENSOR KIT KRP1556 1
68         AIR PRESSURE SENSOR KIT KRP1558 1
69         OIL PRESSURE SENSOR KIT KRP1559 1
70         AIR PRESSURE SENSOR KIT KRP1560 1
71         SENSOR KRP1557 1
72         SPEED SENSOR KRP1551 1
73         SPEED SENSOR KRP1561 1
74         CRANKSHAFT ASSEMBLY CH11176 1
75         CAMSHAFT CH10964 1
76         GASKET KIT - TOP KRP1546 1

日兴动力科技建立了一套完整的英国珀金斯Perkins零配件供应体系,全天候快速供应,从而能够保证您的Perkins机器正常运转。珀金斯Perkins的备用零件的库存齐全,全部采用电脑化管理,随时满足的零件需要纯正珀金斯Perkins配件是您最佳的选择因为您所得到的是延长珀金斯Perkins机器寿命的最佳保证。

注意:网页中公布的配件号与图片仅为参考,因英国珀金斯Perkins零配件型号与技术参数涉及相关因数很多,没能全部展示,如有零配件与维修技术方面的需求,请与本司的在线客服人员沟通与交流,希望我们能够帮您节约更多等待备件到达的时间和维修技术方面的困难。
